Uplus Lighting IP-B420 User Manual

Hide thumbs

Advertisement

Table of Contents

User manual
IP-B420
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-B420 and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting IP-B420

Summary of Contents for Uplus Lighting IP-B420

  • Page 1 User manual IP-B420 Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………3-4 Technical Specifications……………………………………………………………………4 Control Menu …………………………………………………………………………………5-8 DMX Channels ………………………………………………………………… ……………9-11 Dimension ………………………………………………………………… …………………12 6.Trouble Shooting………………………………………………………………………………13 7.Fixture Cleaning………………………………………………………… ……………………13 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...

  • Page 4: Technical Specifications

    Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

  • Page 5: Control Menu

    3.Control Menu 1.Touch panel operation instructions 2. Menu Function Description Display mode Function Address 001—512 Address code settings 2 channel mode Channel 6 channel mode 8 channel mode 11CH 10 channel mode DMX Fail Blackout Drop signal line black field Hold Drop the signal line and keep it 600HZ...
  • Page 6 Speed:00-16 Strobe speed (when the speed is 00, it is static color mixing) Program Auto Speed:01-16 Color jump Fade Fade 01 Speed:01-16 color gradient Fade 02 Speed:01-16 color mutation Fade 03 Speed:01-16 Color changes Sound Sound:01 Voice control color change Sound:02 Voice controlled mutation Sound:03...
  • Page 7 8000K color temperature8000K 8400K color temperature8400K 8800K color temperature8800K 9200K color temperature9200K 9600K color temperature9600K 10000K color temperature10000K WIFI LED_XXX WIFI Mode and link address Wireless DMX Wireless on Clear Clear Connect Configuration wireless off Receive Receiving (slave—status light turns white) Transmit Send (host—status light turns blue)
  • Page 8 Remarks: A. In A001 status mode, press and hold the ENTER key for 3 seconds before the program automatically enters current regulation mode. Press ENTER again to select the color (up and down keys to adjust the value), and then press Menu key to return. B.

  • Page 9: Dmx Channels

    4.DMX Channels Channel 2CH MODE 6CH MODE 8CH MODE 11CH MODE Number 1-255 Total dimming 1-255 1-255 1-255 Red linear Total Total dimming dimming dimming 0-10 Closed light 1-255 1-255 Red linear dimming 11-20 Color temperature 2000K Green linear off light, 21-30 Color temperature 2200K 10-255 31-40bColortemperature 2400K...
  • Page 10 1-255 1-255 1-255 Purple linear White Amber linear dimming dimming linear dimming 1-255 1-255 Amber Purple linear dimming linear dimming 1-255 0-9offlight, Purple 10-255 strobe linear (slow to fast) dimming 0-10 Closed light 11-20 Color temperature 2000K 21-30 Color temperature 2200K 31-40 Color temperature 2400K 41-50 Color temperature 2600K 51-60 Color temperature 2800K...
  • Page 11 CH11 0-255 speed Infrared remote control function: 1、Dimming up button 2、Dimming down key 3、OFF light off pause 4、ON operation 5、R、G、B、W、A、UV keys are 6 monochromes. 6、The 0 key is in the A001 console reception mode, and the up and down keys adjust the address 7、1-9 number keys for 9 mixed colors.

  • Page 12: Dimension

    5.Dimension...

  • Page 13: Trouble Shooting

    6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
