○Piping specifications
Model No.
Port size
Pressure
sensing part
Piping port
Weight
∗: •The form of the G thread (including the major and minor diameter and pitch of the internal thread) is based on JIS B0202 (ISO228-1).
•Products indicated as ISO1179-1 (G thread for hydraulics) or ISO16030 (G thread for pneumatics) are based on JIS B0202
(ISO228-1) for effective depth of thread, seat surface area, surface roughness and squareness.
•For ISO1179-1 (G thread for hydraulics), the withstand pressure is specified for each product. SMC do not guarantee the withstand
pressure specified in ISO1179-1, ISO1179-2, ISO1179-3, or ISO1179-4.
•For ISO16030 (G thread for pneumatics), the withstand pressure is specified for each product. SMC do not guarantee the withstand
pressure specified in ISO16030.
○Analogue output
Voltage output
Range
Vacuum
Compound
Positive pressure
01 N01
R1/8 NPT1/8
(with M5 (with M5
female female
thread) thread)
C3602
(electroless nickel
plating)
O-ring: HNBR
78 g 79 g
Rated pressure range
0.0 to -101.3 kPa
-100.0kPa to 100.0 kPa
-0.100 to 1.000 MPa
W1 WF1 M5
M5×0.8
Rc1/8 G1/8
(female)
Silicone
ZDC2
O-ring: HNBR
97 g 97 g 104 g
Current output
A
-
- -100 kPa
-0.1 MPa
-62-
C4 C6
One-touch One-touch
fitting φ4 fitting φ6
ZDC2, POM, SUS304,
C3604
(electroless nickel plating)
O-ring: HNBR, NBR
101 g 101 g
B C
0 -101.3 kPa
100 kPa
0 1 MPa
No.PS※※-OMM0007-I
