- Page 1 Compact Pressure Switch ZSE1 /ISE1 Series (For Vacuum) (For Positive Pressure) For General Pneumatics RoHS Can be integrated with ZM ejector system. Variable hysteresis Easy and simple wiring 1 to 10% of set pressure (Variable) Connector type...
-
Page 2: How To Order
Compact Pressure Switch RoHS ZSE1/ISE1 Series ZSE30 ISE30 How to Order ZSE40 ISE40 ZSE10 Rated pressure range/ Piping specifications ISE10 Setting pressure range Note 1) ISE70 Note 1) 0 to 1 MPa NPTF 0 to 100 kPa Note 1) M5 x 0.8 (female) threaded. ZSE80 ISE80 ZSE... -
Page 3: Output Specifications
ZSE1/ISE1 Series For details about the Pressure Switch Precautions, refer to pages 763 and 764. For details about the Specific Product Precautions, refer to the Operation Manual at SMC website. Specifications ZSE1 ISE1L ISE1 Model For vacuum For low pressure For high pressure Rated pressure range/Set pressure range 0 to –101 kPa... -
Page 4: Calibration Procedure
ZSE1/ISE1 Series Compact Pressure Switch Calibration Procedure Hysteresis • Hysteresis is the pressure difference between the ON and the Set the ON-pressure by the pressure setting trimmer. Turning OFF pressure of the output signal. The set pressure is the pres- clockwise can set the high pressure/high vacuum pressure. - Page 5 ZSE1/ISE1 Series Compact Pressure Switch Internal Circuits and Wiring Examples -14/-15 -16/-17 NPN (1 output) NPN (2 outputs) Brown DC (+) Brown DC (+) ZSE30 ISE30 Load Load Black OUT1 Black OUT1 ZSE40 ISE40 12 to 24 12 to 24 −...
- Page 6 ZSE1/ISE1 Series Dimensions Grommet type: Connector type: ZSE1-00-14/-15/-18/-19 ZSE1-00-14C/-15C/-18C/-19C Indicator light (Red) Indicator light (Red) Hysteresis setting trimmer Pressure setting trimmer Hysteresis setting trimmer Pressure setting trimmer Indicator light (Red, Green) Indicator light (Red, Green) Pressure setting trimmer 2 Pressure setting trimmer 1 Pressure setting trimmer 2 Pressure setting trimmer 1 Pressure supply...
