•Piping specifications / Matrix table for option 1 and part numbers
Option 1
Description
Bracket A
Bracket B
Bracket D
Panel mount adapter
Panel mount adapter
+ Front protective cover
○Accessories 1 / Part numbers
Part number
ZS-24-A Bracket A with 2 mounting screws each of M3 x 5 L, M4 x 5 L
ZS-24-B Bracket B with 2 mounting screws M4 x 5 L
ZS-24-D Bracket D with 2 mounting screws each of M3 x 5 L, M4 x 5 L
ZS-35-C Panel mount adapter (piping specification: 01, N01)
ZS-35-D Panel mount adapter (piping specification: W1, WF1, M5, C4, C6)
ZS-35-F Panel mount adapter + Front protective cover (piping specification: 01, N01)
ZS-35-G Panel mount adapter + Front protective cover (piping specification: W1, WF1, M5, C4, C6)
Symbol Part number
A ZS-24-A
B ZS-24-B
D ZS-24-D
ZS-35-C
E
ZS-35-D
ZS-35-F
F
ZS-35-G
-10-
Piping specification
01 N01 W1 WF1
Ο Ο Ο Ο
× × Ο Ο
Ο Ο Ο Ο
Ο Ο × ×
Ο Ο
× ×
Ο Ο × ×
× × Ο Ο
Option 1
M5 C4 C6
× × ×
× × ×
× × ×
× × ×
Ο Ο Ο
× × ×
Ο Ο Ο
