○Tube attachment
•When the product is used in a place where water and dust splashes may occur, insert a tube into the
atmospheric vent port, and route the other end of the tube to a safe place away from water and dust.
(Refer to the figure below)
∗: Insert the tube into the atmospheric vent port until it bottoms out.
∗: SMC TU0425 (polyurethane, O.D φ4, I.D φ2.5) is a suitable tubing.
-19-
No.PS※※-OMM0007-I
