Summary of Contents for Rittal Micro Data Center Level E
- Page 1 Micro Data Center Level E Micro Data Centre Level E 7999.009 Bedienungsanleitung Operating instructions...
- Page 4 Rittal GmbH & Co. KG Auf dem Stützelberg 35745 Herborn Germany Tel.: +49(0)2772 505-0 Fax: +49(0)2772 505-2319 E-mail: info@rittal.de www.rittal.com www.rittal.de We are always happy to answer any technical questions regarding our entire range of products. Rittal Micro Data Centre Level E...
-
Page 5: Table Of Contents
Inspection and maintenance ....24 Safety instructions ........24 Maintenance of the safety cell ......24 Maintenance contract ........24 Storage and disposal ......25 Storage ............25 Disposal ............25 Technical specifications ....26 Accessories ........26 Rittal Micro Data Centre Level E... -
Page 6: Notes On Documentation
Micro Data Centre Level E Notes on documentation Manufacturer's statement Rittal GmbH & Co. KG confirms that the applicable safety standards for the Micro Data Centre Level E are observed. Storing the documents The operating instructions as well as all applicable documents are integral components of the product. -
Page 7: Safety Instructions
Micro Data Centre Level E Safety instructions Explosion hazard The Micro Data Centre Level E produced by Rittal If UPSs with integrated or separate bat- GmbH & Co. KG is developed and produced with due tery packs are installed in the Micro Data regard to all safety precautions. -
Page 8: Safety Notes For The Prevention Of Damage To The Micro Data Centre
The customer is responsible for the correct operation of the condensate dis- charge routed through the cable duct. Rittal Micro Data Centre Level E... -
Page 9: Operating And Technical Staff
After the commissioning of the Micro Data Centre, do not have any keys duplicated by a key service. If you require additional keys, please contact the Rittal service depart- ment. If keys get lost, the lock must be replaced without delay. -
Page 10: Product Description
Components of the Micro Data Centre Product Description Functional description The Rittal Micro Data Centre Level E is a modularly ex- tendible IT security safe. It provides physical safety and protects against fire, water, acrid gases and un- authorised access. -
Page 11: Standard System Components
The cable box for the introduction of data and supply and maintenance conditions. cables consists of a sheet steel enclosure lined on all sides with alkaline-silicate blocks. In case of fire or Rittal Micro Data Centre Level E... -
Page 12: Dimensions And Clearances
Micro Data Centre Level E Rittal GmbH & Co. KG is not responsible for any dam- age which may result from failure to comply with the documentation provided. The same applies to failure to comply with the valid documentation for accesso- ries used. -
Page 13: Assembly And Siting
The customer must connect the frame correctly as adequate storage and mounting area in the im- with the potential equalisation rail. If Rittal's IT mediate vicinity of the installation site area. frame is used, the scope of supply includes a cen- 2. - Page 14 [2] and permitted uniformly distributed characteristic live loads of q 7.5 kN/m². Rittal Micro Data Centre Level E...
-
Page 15: Average Surface Load Of The Micro Data Centre Level E
Micro Data Centre Level E. Rittal Micro Data Centre Level E, 47 U, 1000 mm interior depth with two single-leaf doors Average surface load assuming a total weight of 1230 kg Components... - Page 16 Micro Data Centre Level E Rittal Micro Data Centre Level E, 47 U, 1200 mm interior depth with two single-leaf doors Average surface load assuming a total weight of 1340 kg Components Weight [kg] (based on one Micro Data Centre) Mico Data Centre Level E Line a.) 437 kg/m2 on a bare floor...
-
Page 17: Transport
Micro Data Centre Level E Transport Note: The Micro Data Centre may be transported only by trained specialists certified by Rittal GmbH & Co. KG. Rittal Micro Data Centre Level E... -
Page 18: Installation And Commissioning
The safety of the configuration must be ists certified by Rittal GmbH & Co. KG. checked for the installation of units without official approval. The installation of the units... -
Page 19: Operation
Before you lock the Micro Data Centre, en- a key service. If you require additional keys, sure that no key is still contained within it please contact the Rittal service depart- (not even an emergency key)! ment. The interior of the Micro Data Centre must... -
Page 20: Electronic Combination Lock Combi B 90
80% (non-condensing). Combi B lock is valid. The lock must never be greased with or contact other lubricants or aggressive liquids, it must be cleaned only with a moist cloth only (no aggressive cleaning agents). Rittal Micro Data Centre Level E... - Page 21 Code can be used only after it has been activated. When activating a new operator, it is useful if the new code (starting from item 3 of the above description) is entered directly by the respective operator on site. Rittal Micro Data Centre Level E...
- Page 22 Code input is not required. Further functions such as the use of double codes, opening delay, blocking or unblocking of user codes can be found in the enclosed operating instructions for the lock. Rittal Micro Data Centre Level E...
- Page 23 Fig.4.4: Move the top part of the input unit in Fig.4.5: Remove the top part of the input unit Fig.4.6: Replacing the batteries. the direction of the arrow to the stop. carefully. Mounting in the reverse order. Rittal Micro Data Centre Level E...
- Page 24 Allen wrench square shaft. into the small hole on the bottom side and pressed. press it in to the stop. Fig. 5.4: Inserting the key. Fig. 5.5: Turning the key clockwise to the stop. Rittal Micro Data Centre Level E...
-
Page 25: Electronic Lock For Activation By An Access Control System
7 = positive trigger voltage See above See above 8 = negative trigger voltage Input unit Not assigned Pin1 of the respective socket Fig. 7: Interfaces Fig. 8: Pin assignment White Grey Brown Pink Green Blue Yellow Rittal Micro Data Centre Level E... -
Page 26: Inspection And Maintenance
We recommend that you have a maintenance contract for an annual inspection. These safety inspections guarantee the full operability of the Micro Data Centre Level E. For questions concerning service and maintenance contracts, please contact our service operation: Tel.: +49(0)2772 505-1717 Rittal Micro Data Centre Level E... -
Page 27: Storage And Disposal
Micro Data Centre Level E Storage and disposal Storage If the device is not used for a long period, Rittal rec- ommends that it is disconnected from the mains pow- er supply and protected from dampness and dust. Disposal The materials of the Micro Data Centre should be han- dled as household refuse. -
Page 28: Technical Specifications
The Micro Data Center Level E IT rack frame can be equipped with various accessory components, including: CMC monitoring system Fire alarm and extinguishing system Busbars Rack accessories You can find the corresponding components on the Rittal homepage or get in touch with your contact at Rittal. Rittal Micro Data Centre Level E... -
Page 29: Appendixes
The condensate discharge is routed through the ca- ble ducts of the Micro Data Centre by the assembling Rittal Micro Data Centre Level E... -
Page 30: Warranty
Micro Data Centre, the validity of the recog- nition of the test ratings is voided. In such cases, please contact the manufacturer without delay otherwise the warranty is voided. Rittal Micro Data Centre Level E... -
Page 31: Customer Service Addresses
Micro Data Centre Level E Customer service addresses For technical questions, please contact: Tel.: +49(0)2772 505-9052 E-mail: info@rittal.de Homepage: www.rittal.com For complaints or service requests, please contact: Tel.: +49(0)2772 505-1855 E-mail: service@rittal.de Rittal Micro Data Centre Level E... - Page 32 Micro Data Centre Level E ◼ Enclosures ◼ Power Distribution ◼ Climate Control ◼ IT Infrastructure ◼ Software & Services RITTAL GmbH & Co. KG Postfach 1662 · D-35726 Herborn Phone +49(0)2772 505-0 · Fax +49(0)2772 505-2319 E-mail: info@rittal.de · www.rittal.com...
