After filling in all the necessary data, the user creates the Job by clicking on
86
the Create icon. At this point, the Job is saved and the job cannot be started.
This function is suitable for the Job preparation. It will be traceable in the Jobs
tab when you can click on it at any time to start the job. Or the user can click
on the icon Create and start and can start the job immediately. The user must
follow the sequence of tasks passed to the user by the portal as is shown in
the following figure.
The portal guides the user intuitively through the individual mowing processes
required with the SPIDER AUTONOMOUS 2.0. On the map, the user can see
the location of his machine and the correction station. If the user clicks on
the mower on the map, a tab of the machine opens showing its status, the
recorded route, its position on the map, see picture below. When the mowing
is finished, the user clicks on the Complete job icon, which completes the Job
and its progress can be traced in the Jobs tab.
12

Maintenance

12.1 MOWER MAINTENANCE PLAN

The above control tasks
are carried out by
the MACHINE USER
VISUAL INSPECTION FOR OIL LEAKS IN
THE ENGINE AND HYDRAULIC SYSTEMS
LUBRICATION OF GUIDE RODS
WITH GREASE
(at least once per season)
LUBRICATION OF OTHER LUBRICATION
POINTS WITH SPRAY DRY LUBRICANT
CHECKING THE HYDRAULIC FLUID
LEVEL IN THE RESERVOIR
CHECKING TIRE PRESSURE
VISUAL CHECK OF THE TENSION
OF THE V-BELTS
VISUAL CHECK OF CHAIN TENSION
FOR WHEELS TURNING
CHECKING THE BATTERY CHARGE
OF THE REMOTE CONTROL
INTERVAL ACCORDING TO THE STATUS
OF THE ENGINE HOUR COUNTER
daily every every every
before 50 200 800
use hours hours hours
• •
•
• •
• •
• •
• •
• •
•
