C O N N E C T I N G P O W E R A N D D A T A

1 . C O N N E C T I N G P O W E R
The luminaire requires standard AC power distribution from 200-240 VAC, 50/60 Hz. Current required
depends on the AC supply voltage and product model. Refer to
covered in this manual.
NO TE: The mating Neutrik® powerCON® True1 connector is supplied; however, you will need to purchase or
construct a cable appropriate for your application. Available power input cables is found in
Items/Accessories" on page
Depending on the application, the luminaire's AC input cable may require a different connector. If required,
install a new connector meeting your requirements using the following wire color code reference:
WARN IN G! DO NOT connect to three-phase service in countries with 240 volt power. AVERTISSEMENT:
NE PAS se connecter au service en trois phases dans les pays avec puissance de 240 volts.
For single-phase power at 240 volts RMS:
For three-phase power at 200 volts RMS:
WARN IN G! It is not recommended to power any Vari-Lite luminaire from a dimmer - even in 'NONDIM'
mode. Dimmer and non-dim modules are not suitable sources of power because their output modifies the AC
wave form. This may work for a short time, but will eventually result in power problems, luminaire mis-
operation and/or failure and may void the luminaire's warranty.
recommandé pour alimenter un luminaire Vari-Lite d'un gradateur - même en mode 'NONDIM'. Modules de
gradation et non sombres ne sont pas des sources appropriées de pouvoir parce que leur production modifie
8.
FI GU RE 2: P OW ER CO NNE CT OR
W I R E *
Green/Yellow
Blue
Brown
* International (Harmonized) Standard
C ON N E C TI O N P I N
AC Neutral X
AC Line Y
Ground (Earth) G
C ON N E C TI O N PI N
Phase 1 X
Phase 2 Y
Ground (Earth) G
"Current vs. Voltage" on page 7

AC POWER INPUT

Neutrik® powerCON True1

AC INPUT CONNECTOR

C O NNE C TI O N
AC Ground
AC Neutral
AC Line
X
G
Y
X
G
Y
A V E R T I S S E M E N T
CONNECTING POWER AND DATA
VL6000 BEAM
for all models
"Replacement
: Il n'est pas
6
