- Page 1 Bedienungsanleitung instrucciones de manejo mode d'emploi gebruiksaanwijzing Astro 100CM RGBW, 01107190 120W, 100/260V DMX512 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo MN, Italy. tel +39 0376 771 777 ‐ email info@ldr.it...
-
Page 2: English - Table Of Contents
page 15 20.2 DMX chart 2 page 16 20.3 DMX chart 3 page 16 20.4 DMX chart 4 page 17 LDR Conformity Certificate – Certificato di Conformità – Konformitätserklärung page 18 Complaint form – Modulo di reclamo – Reklamationsformular …………………………. page 19 WEEE Directive – Direttiva RAEE – WEEE Richtlinie …………………………………………… page 20 1 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... - Page 3 1. IMPORTANT SAFETY NORMS this product is a professional lighting fixture, which can only be operated by professional staff. Warning, high voltage ignition. Disconnect the unit from power before servicing Continuous mains power is required for this spotlight as an internal dimmer controls the intensity via DMX or local rotary knob. Use of a phase control dimmed mains supply may damage the internal electronics. This product features fan‐assisted ventilation. Make sure you do not cover the fans or obstruct the air flow at any one time. Make sure the fans are working correctly. Should you detect even the slightest malfunction, switch the luminaire off and carry out the necessary servicing. Replace the fan if necessary. This product is rated IP20 and is therefore designed for interior use only. For details on maximum ambient temperature, minimum distance from flammable objects and minimum distance from lit surface, please refer to the product label or the screen‐printed information to be found on the rear plate and front side of each luminaire. 2 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
-
Page 4: Box Contents
There are no user serviceable parts in this product. Replacement of any internal component of this product must be carried out exclusively by professional personnel and only with original Luci della Ribalta srl components. Replacement of any part of the wiring system must comply with the original wiring diagram and with components identical or compatible with those originally fitted. Installation of this product must be exclusively carried out by professional personnel in compliance with the safety norms in force in the country where the product is used. WARNING: DANGER OF ELECTRICAL SHOCK DO NOT OPERATE ON LIVE EQUIPMENT Disconnect power before opening this fixture to access its light source or electronics. The replacement of the LED source or any of its electronic components can be carried out exclusively by professional personnel upon LDR’s written authorization and only with original Luci della Ribalta srl components. Failure to obtain the manufacturer’s authorization to carry out the replacement/repair, will immediately invalidate the product’s warranty WARNING: EYE DAMAGE HAZARD Make sure this fixture is installed so as to avoid prolonged direct staring at its operating light source (LED) from a distance of less than 7m / 23ft. WARNING: FIRE HAZARD Never locate this fixture on any flammable surface. Minimum distance of any part of the body of the luminaire from any flammable surface: 0,5m Minimum distance from lit surface, please refer to product label Make sure the mains power supply the fixture will be connected to is protected by a suitable ... -
Page 5: Weight And Dimensions
A spigot is supplied in standard delivery for you to tripod‐mount your followspot. Make sure the tripod you are going to use can withstand the product load as indicated on the product’s label and here above Make sure the tripod you are going to use features a top aperture over 28mm dia. Remove the M12 nut and the washer from the spigot. Insert the spigot in the central hole of the yoke of the followspot from beneath the yoke. Add the plain screw and the M12 self‐ locking nut and tighten the nut with a suitable tool. Mount the followspot on the tripod. 5. MOUNTING THE COLOUR CHANGER (accessory, part nr. 20105103) This section only applies in case you bought the followspot and the colour changer separately. In case you bought a kit model the colour changer will be already fitted. Mount the colour filters on the colour changer unit. See relevant instructions supplied with the colour changer. At the front of the followspot, slacken the 3 cross‐head black M4 screws (two at the top angles, one at the bottom, left‐hand side angle) so that they remain inserted approximately half‐way through. Position the colour changer unit on the front plate of the follow spot, making sure that the colour levers are positioned on the left‐hand side of the follow spot when viewed from the front and hang it to the previously positioned screws. Release the colour filters of the colour changer by pressing the black, flat lever in order to have access to the screws 4 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... - Page 6 Slide the diaphragm in the gate area. Fix the iris in position by tightening the previously removed screws Important notice: do not leave the iris closed for over 5 minutes while the LED is on FAILURE TO COMPLY WITH THE ABOVE NOTICE MAY CAUSE THE IRIS AND THE FOLLOWSPOT TO SUFFER MAJOR HEAT DAMAGES AND WILL INVALIDATE THE PRODUCT WARRANTY 7. SHUTTER BLADES (accessory, part nr. R80208019 x 4) Shutter blades are not supplied with the unit but are available as separate accessory. They are sold as single items and relevant part number is R80208019, 4 are required. IMPORTANT NOTICE BEFORE THE INSTALLATION / INSTALLATION This fixture is meant for tripod‐mount installation only. No hanging is allowed Before installing this fixture check its weight on the product label and the weight of each accessory you are adding and make sure the structure you are installing it to withstands the total weight. The mounting stirrup is designed to allow the spotlight to be fitted to a suitable tripod or pole. CAUTION DO NOT TURN THE LUMINAIRE UPSIDE‐DOWN AND MAKE SURE THE STIRRUP ALWAYS SITS DOWNWARDS Note: the spotlight’s location must provide suitable ventilation for the LED module. 9. WIRING Before being connected to the mains power, this unit may need to be wired with a suitable plug if not already installed. Make sure the plug you are using is rated for the proper power load. 5 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
-
Page 7: Connect To The Power Supply
Before you finally position this product for use, temporarily connect it to a properly fused power supply to check the unit works correctly. VOLTAGE Before operating this unit please refer to the product label mounted at the back of the luminaire to check you are operating with the correct voltage. The Astro 100 LED can be operated between 100V and 260 VAC. 11. FREQUENCY Frequency on this product is automatically selected by the electronic PSU (50/60Hz) 12. CONNECT TO THE POWER SUPPLY Connect the unit to a continuous mains power source Make sure the power supply is protected by a suitable thermal magnetic circuit breaker This fixture must be grounded 13. MECHANICAL OPERATION Focus control: this fixture features a variable beam angle from 10° to 28° which can be controlled through the two control knobs on the right‐hand side of the lens‐tube. The variable beam is modified by adjusting the front and rear zoom lenses in relation to each other. The front lens defines the beam spread, the rear lens defines the focus degree of ‘softness’ or ‘hardness’ of the beam edge or shutters. Gently turn the knobs anti‐clockwise until you have reached the desired size/focus of the beam in relation to the distance you are projecting at. Turn the knobs clockwise and tightly close them so that the lenses are held in position at any tilt angle 6 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 8: Functions And Operation
ARROW SHOULD AND PRESS TO APPEAR CONFIRM Tap the rotary selector and the LCD screen will display the mode status and the current value: 1 Mode M: DMX 00 % = LED OFF TAP THE ROTARY 100 % = LED FULL SELECTOR TO DISPLAY XX % THE VALUE 00 % (000) = LED OFF 1 Mode M:Manual TAP THE ROTARY 100% (FFF) = LED FULL SELECTOR TO DISPLAY XX % XXX MANUAL THE VALUE 7 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... - Page 9 OFF=00% 15.5 STROBE (Strobe) This function enables the activation of the strobe function. Factory setting is DISABLE. PRESS TO ACTIVATE 5 Strobe 5 Strobe 5 Strobe TURN TO ENABLE OR THE MENU, AN DISABLE STROBE AND DISABLE ENABLE DISABLE ARROW SHOULD PRESS TO CONFIRM APPEAR 8 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 10 This function allows to set the LED dimming response. Factory setting is NORMAL. PRESS TO ACTIVATE 9 Smooth 9 Smooth THE MENU, AN FAST DIMMING NORMAL NORMAL ARROW SHOULD RESPONSE = 150ms APPEAR 9 Smooth SLOW DIMMING SLOW RESPONSE = 300ms 9 Smooth IMMEDIATE DIMMING FAST RESPONSE 9 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 11 PRESS TO CONFIRM APPEAR 15.13 GREEN COLOUR INTENSITY (Green) This function allows to set the intensity of the green colour for manual mode. Selecting the manual mode, 100% is automatically set. PRESS TO ACTIVATE TURN TO SELECT THE 13 Green 13 Green 13 Green THE MENU, AN GREEN INTENSITY ###% ARROW SHOULD AND PRESS TO ###% ###% APPEAR CONFIRM 10 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 12 BASIC ProBasic ARROW SHOULD PRESS TO CONFIRM APPEAR 15.19‐B FACTORY SETTINGS (Reset) The RESET control is a special function which allows to RESET the product to factory settings. Choose Are You MenuType PRESS TO ACTIVATE PRESS TO CONFIRM BASIC Reset SURE ? THE MENU THE RESET 15.20‐C ID REMOTO (ID Rem) It allows to select the ID number to connect the ASTRO to REMOTO, a device which allows to upload and download firmware and to update the ASTRO software version. To change the initial ID press the rotary switch until an arrow appears, then turn to change to the desired ID number. Press to confirm your selection. It is possible to select an ID number from 0 to 250. If ID number=0 the remote control is not active. 11 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
-
Page 13: Cleaning And Maintenance
VALUE AND PRESS TO #### #### CONFIRM 15.22‐E EXIT HIDDEN MENU (Exit) It allows to exit from hidden menus. 16. CLEANING AND MAINTENANCE To ensure maximum performance of the product, a regular maintenance service should be carried out. Please make sure the product is cold and disconnected from power supply when doing this. General maintenance * Clean all reflective parts such as lenses opening the product, if necessary. * Check the lenses and replace any visibly damaged component. * Clean air ducts and fans in order to allow a proper ventilation activity on the product. * Check internal and external wiring and replace any cable which should be damaged by heat or mechanical agents. Cleaning of optical components LEDhouse lenses: Open the lens compartment door by removing the two M4 cross head screws on the top of the ledhouse tube and slide the top cover free Remove the condensor lenses assembly by removing the two M5 cross head screws. Clean the lenses with a soft cloth and re‐position Zoom lenses: Slide the front zoom panels positioned at the bottom of the lens tube and clean with a soft cloth. 12 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 14: Spare Parts
Astro 100 RGBW, DMX 512 + RDM LED followspot ‐ User’s Manual – 1.0 17. SPARE PARTS All components are available as spare parts. We strongly recommend you always use original LDR components as spare parts. Please refer to our technical assistance should you need to order and/or replace any part of the unit. 18. WARRANTY Our warranty covers all structural and manufacture defects for two years from the date you purchased this product. In case of complaints we strongly recommend you use the complaint form at the end of this manual or contact the local dealer who supplied the product to you. In any case please report the serial number of the product. In case of complaints under warranty proof of purchase will have to be provided. 13 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... - Page 15 12 Red Red intensity for manual mode From 00% to 100% ‐‐‐ 13 Green Green intensity for manual mode From 00% to 100% ‐‐‐ 14 Blue Blue intensity for manual mode From 00% to 100% ‐‐‐ 15 White White intensity for manual mode From 00% to 100% ‐‐‐ 16 Tled Visualize the LED temperature Select the LED Temp in °C or F° °C 17 SwVer Visualize the software version ‐‐‐ 14 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 16 Proportional setting of the blue colour 5 Blue Proportional 0 ‐ 255 0% ‐ 100% from 0 to 100% Proportional setting of the white colour 6 White Proportional 0 ‐ 255 0% ‐ 100% from 0 to 100% ASTRO 100 RGBW Chart name: DMX512 Functions chart 1 (Default) Issue: 1.0 Date: May 2023 Luminaire: 15 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 17 161 ‐ 180 64% ‐ 71% Step Strobe speed 9 181 ‐ 200 72% ‐ 78% Step Strobe speed 10 (maximum frequency) 201 ‐ 220 79% ‐ 86% Step Closed 221 ‐ 255 87% ‐ 100% ASTRO 100 RGBW Chart name: DMX512 Functions chart 3 (Strobe) Issue: 1.0 Date: May 2023 Luminaire: 16 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 18 181 ‐ 200 72% ‐ 78% Step Strobe speed 10 (maximum frequency) 201 ‐ 220 79% ‐ 86% Step Closed 221 ‐ 255 87% ‐ 100% Chart name: DMX512 Functions chart 4 (16 bits + ASTRO 100 RGBW Issue: 1.0 Date: 2023 Luminaire: Strobe) Luci della Ribalta srl reserves the right to modify the present document without prior notice. 17 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 19 P .iva 01815640204 c.iso IT01815640204 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo MN Italy - tel +39 0376 771777 - web www.ldr.it - email info@ldr.it IT/015/MN/11 VAT registration # It01815640204 - REA MN 198438 - Authorized Exporter #...
- Page 20 Reklamationsformular ‐ formulaire de réclamation ‐ hoja de reclamaciones email: info@ldr.it Azienda ed Indirizzo ‐ Company's name and address ‐ Firmenname und Addresse ‐ Nom et adresse ‐ Nombre y direcciòn _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ Nome del rivenditore da cui il prodotto è stato acquistato ‐ Name of the dealer where you have purchased the product ‐ Namen der Firma, die Ihnen das Produkt verkauft hat ‐ Nom de la société qui vous a vendu ce produit ‐ Nombre de la compañia donde han comprado el producto: ____________________________________________________________________________________________________ 01107190 Astro 100CM RGBW, Prodotto difettoso 120W, 100/260V DMX512 Faulty product Defekte s Produkt Produit défectueux Producto defectuoso Descrizione del problema /Problem found/Beschreibung des Defekts/Description du défaut/Descripciòn del problema ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ Data d'acquisto ‐ Date of purchase ‐ Kaufdatum ‐ Date de l'achat ‐ Fecha de compra ________________________ Si prega di allegare prova d'acquisto ‐ Please attach copy of purchase invoice ‐ Bitte Kaufnachweis beilegen ‐ Veuillez joindre une quittance d'achat ‐ Les rogamos incluyan lcopia de la factura de compra. Nome e qualifica ‐ Name and position ‐ Name und Funktion ‐ Nom et fonction ‐ Nombre y cargo ____________________________________________________________________ Data ‐ Date ‐ Datum ‐ Date ‐ Fecha _____________________________...
- Page 21 local de escoamento de residuos, ou a loja na qual efectuou a compra. Richtlinie 2002/96/EU (Elektro- und Elektronik- Altgeräte - WEEE): Benutzerinformationen. Dieses Produkt entspricht Richtlinie WEEE-symbolet (Waste Electrical 2002/96/EU. Das Symbol des auf dem Gerät Electronic Equipment). dargestellten, durchgestrichenen Korbes gibt an, dass Bruken av WEEE-symbolet indikerer at dette Produkt Ende...
- Page 22 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo mn Italy. tel +39 0376 771 777 ‐ fax +39 0376 772 140 ‐ email info@ldr.it...
