9.0 Parameter Menu
(cont...)
N°
Default value & other possibilities
04 SurF: Front Panel Temperature Limitation (cont...)
Surface Single Double
Setting
Temperature Panel Panel
no ~ 90°C max 1 1
Mid ~ 75°C max ~ 0.70 ~ 0.90
Lo ~ 60°C max ~ 0.55 ~ 0.80
E.g. A 1000 Watt single panel programmed for a maximum surface temperature of
75°C will deliver maximum 700 Watts. A 1000 Watt double panel programmed for
a maximum surface temperature of 60°C will deliver maximum 800 Watts. These
values should be considered when selecting the number and type of panels to
cover the calculated heat losses.
05
Firmware Version
Displays the MCU and ZigBee firmware alternately every 2 seconds.
06 Wind: Open Window Detection
(the text "U – ind" is displayed)
Press the "OK" key to enter this parameter. Select with "+" or "-" and confirm by
pressing the "OK" key:
no: open window detection function disabled.
YES: open window detection function enabled (default). The
LCD display, is constantly displayed.
This function will switch the radiator from any active mode to "Frost Protection"
mode when an open window is detected (room temperature drops within a certain
time). The open window icon
the function is active.
To return to the previous or automatic mode, press the "OK" key twice.
NOTE: If connected to a Unisenza+ Gateway, this setting will not be available.
07 ItCS: Adaptive Start
Press the "OK" key to enter this parameter. Select with "+" or "-" and confirm by
pressing the "OK" key:
no: adaptive start function disabled. Heating up to reach the Comfort set
temperature will start at the programmed time.
YES: adaptive start function enabled (default).
Heating up will start at the predicted optimal time to reach the Comfort set
temperature at the programmed time.
The , in section 5 of the LCD display, is constantly displayed (programme mode
only). The adaptive start icon
, in section 8 of the
will start to blink, and continue to blink as long as
will blink when pre-heating commences.
9.0 Parameter Menu
(cont...)
N°
Default value & other possibilities
07 ItCS: Adaptive Start (cont...)
NOTE: Heating start times will vary for each heating period when this function
is enabled.
NOTE: If connected to a Unisenza+ Gateway, this setting will not be available.
08 SLA or FOLL: (NOT USED)
Factory set to "no" and must not be altered.
NOTE: If connected to a Unisenza+ Gateway, this setting will not be available.
09 CLr: Factory Setting
Press and hold the "OK" key for 6 seconds to reset Set point temperatures and all
user parameters in this menu to factory default settings.
NOTE: Pairing with the Unisenza+ Gateway will be lost.
The screen will go blank, the LCD screen will illuminate and all segments will be
displayed for a few seconds, before displaying the software version. The "Comfort"
mode screen will then appear.
10 hour: Time Setting
NOTE: If power is lost, from a power cut or the product is switched off, even just
for a few seconds, the time and day setting will be lost.
NOTE: If connected to a Unisenza+ Gateway, this setting will not be available.
no: time setting disabled (default).
YES: time setting enabled.
The hour value will blink. Adjust the hour value by pressing the "+" or "-" keys,
l
then confirm by pressing the "OK" key.
The minute value will blink. Adjust the minute value by pressing the "+" or "-"
l
keys, then confirm by pressing the "OK" key.
The day values, in section 2 of the LCD display, will blink. Adjust the day value
l
by pressing the "+" or "-" keys, then confirm by pressing the "OK" key.
The "Comfort" mode or previously selected operating mode screen will appear.
l
