Device ID Display:
HEALTH LED:
PWR 1 LED:
PWR 2 LED:
USB connector:
USB LED:
RS232 connector:
LAN LINK:
S1:
S2:
UP:
L1:
L2:
MUTE
Sample rate LED:
10 PG8-INTERCOM-FX and PG4-INTERCOM-FX User Guide
The identification number (ID) of the device
Green: Power supply to the device works, temperature is within limits
Green: Power supply 1 is operational and receiving power
Green: Power supply 2 is operational and receiving power
USB connection for remote control from a computer
Green static: Indicates physical USB connection
Green flashing: Indicates data activity (software/server online)
RS232 (D Sub 9) connection for remote control and firmware updates
Ethernet communication is established via SANE 1 (rear panel)
Ethernet communication is established via SANE 2 (rear panel)
Another device with enabled Ethernet is on the network
Ethernet communication is established via LAN 1 (rear panel)
Ethernet communication is established via LAN 2 (rear panel)
Red static: Output mute indicator. Nothing is routed to the output.
Yellow: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
