Model No. PFEVEL89716.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFEVEL89716.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form PFEVEL89716.1

Summary of Contents for Pro-Form PFEVEL89716.1

  • Page 1 Model No. PFEVEL89716.1 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 18. The elliptical does not have a freewheel; the 20. Over exercising may result in serious injury pedals will continue to move until the fly- or death. If you feel faint, if you become short wheel stops. Reduce your pedaling speed in of breath, or if you experience pain while a controlled way.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM reading this manual, please see the front cover of this ® ENDURANCE 720 E elliptical. The ENDURANCE manual. To help us assist you, note the product model 720 E elliptical provides an impressive selection of number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you finish all assembly steps.
  • Page 8 3. Press the Cover Mounts (106) on the underside of the Rear Stabilizer Cover (15) into the Rear Stabilizer (2). 4. With the help of a second person, place some of the packing materials (not shown) under the front of the Frame (1). Have the second per- son hold the Frame to prevent it from tipping while you complete this step.
  • Page 9 5. Orient the Upright (4) as shown. Have a second person hold the Upright near the Frame (1). Locate the wire tie (A) in the lower end of the Upright (4). Tie the wire tie to the Main Wire (110) as shown in the inset drawing. Then, pull the upper end of the wire tie until the Main Wire is routed through the Upright.
  • Page 10 7. Using a plastic bag to keep your fingers clean, apply some of the included grease to the Pivot Axle (35). Then, insert the Pivot Axle through the Upright (4) and center it. Tip: It may be helpful to use a rubber mallet. Next, identify the Right Upper Body Leg (60) and orient it as shown.
  • Page 11 9. Untie and discard the wire tie on the Main Wire (110). While a second person holds the Console (7) near the Upright (4), connect the wires on the Console to the Main Wire (110) and to the Sensor Wires (63). Insert the excess wire into the Upright (4).
  • Page 12 12. Apply grease to a Pedal Arm Axle (64). While a second person holds the front end of the Right Pedal Arm (58) inside the bracket on the Right Upper Body Leg (60), insert the Pedal Arm Axle (64) into both parts from the direction shown.
  • Page 13 14. Identify the Right Arm Front Cover (65) and orient it as shown. Attach the Right Arm Front Cover (65) to the Right Upper Body Leg (60) with an M4 x 16mm Screw (101). Next, identify the Right Arm Rear Cover (66) and orient it as shown.
  • Page 14 16. Orient the Shield Cover Cap (118) and the Shield Cover (75) as shown. First, press the tabs on the Shield Cover Cap (118) into the Left and Right Shields (73, 74). 73, 74 Then, press the tabs on the Shield Cover (75) into the Left and Right Shields (73, 74).
  • Page 15 18. Attach the Tablet Holder (127) to the back of the Console (7) with four Tablet Holder Screws (111); start all the Tablet Holder Screws, and then tighten them. 19. Make sure that all parts are properly tightened before you use the elliptical. Extra parts may be included. Place a mat beneath the elliptical to protect the floor.

  • Page 16: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should 1. Plug the indicated end of the power cord into the malfunction or break down, earthing provides a path of socket on the frame.
  • Page 17 HOW TO MOVE THE ELLIPTICAL HOW TO LEVEL THE ELLIPTICAL Due to the size and weight of the elliptical, moving If the elliptical rocks slightly on your floor during use, it requires two persons. Stand in front of the elliptical, turn one or both of the leveling feet (D) beneath hold the upright (A), and place one foot against one of the rear stabilizer or turn the leveling foot (E) under...
  • Page 18 HOW TO ADJUST THE POSITIONS OF THE PEDALS Each pedal (G) can be adjusted to several positions. To adjust each pedal, simply pull the pedal handle (H) outward, move the pedal to the desired position, and then release the pedal handle into an adjustment hole beneath the pedal.
  • Page 19 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even connect your personal audio player to the console sound system and listen to your favorite The advanced console offers an array of features music or audio books while you exercise. designed to make your workouts more effective and enjoyable.
  • Page 20 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the elliptical has been exposed to 1. Begin pedaling or press any button on the cold temperatures, allow it to warm to room tem- console to turn on the console. perature before you turn on the power.
  • Page 21 4. Follow your progress with the display. The matrix offers several display tabs. Press the increase and decrease buttons next to the Enter The display can show the following workout button repeatedly until the desired tab is shown. information: Speed—This tab will show a profile of the speed settings of the workout.
  • Page 22 Change the volume level of If the display does not show your heart rate, make the console by pressing the sure that your hands are positioned as described. volume increase and decrease Be careful not to move your hands excessively or buttons.
  • Page 23 HOW TO USE AN ONBOARD WORKOUT height of the flashing segment indicates the target rpm or the resistance level for the current segment. 1. Begin pedaling or press any button on the console to turn on the console. At the end of each segment of the workout, a series of tones will sound and the next segment of See HOW TO TURN ON THE POWER on the profile will begin to flash.
  • Page 24 4. Follow your progress with the display. HOW TO USE THE CHARGING PORT See step 4 on page 21. The console features a charging port that you can use to charge USB-compatible devices, such as smart- 5. Measure your heart rate if desired. phones, while you exercise.
  • Page 25 HOW TO CONNECT YOUR TABLET TO THE 5. Disconnect your tablet from the console if CONSOLE desired. The console supports Bluetooth connections to tab- To disconnect your tablet from the console, first lets via the iFit–Smart Cardio Equipment app and to select the disconnect option in the iFit–Smart compatible heart rate monitors.
  • Page 26 HOW TO CHANGE CONSOLE SETTINGS Incline System Calibration—If the incline sys- tem is not functioning properly, it may need to be 1. Select the settings mode. calibrated. To calibrate the incline system, press the Quick Ramp increase or decrease button. The To select the settings mode, press the gear button.

  • Page 27: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE If lines appear in the console display, see HOW TO CHANGE CONSOLE SETTINGS on page 26 and Regular maintenance is important for optimal adjust the contrast level of the display. performance and to reduce wear. Inspect and properly tighten all parts each time the elliptical is used.
  • Page 28 HOW TO ADJUST THE REED SWITCH Next, slightly loosen the indicated M4 x 16mm Screw (101). Slide the Reed Switch (38) slightly closer to or If the console does not display correct feedback, the away from the Magnet (43), and retighten the Screw. reed switch should be adjusted.
  • Page 29 HOW TO ADJUST THE DRIVE BELT See EXPLODED DRAWING C on page 35. Identify the Left and Right Shields (73, 74). Remove If the pedals slip while you are pedaling, even while the M4 x 19mm Screws (5), the M4 x 25mm Screws the resistance is adjusted to the highest level, the drive (139), and the M4 x 48mm Screw (107) from the Left and Right Shields;...

  • Page 30: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 31: Part List

    PART LIST Model No. PFEVEL89716.1 R1018A Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Right Pedal Ramp Axle Cover Upright Pivot Spacer M4 x 19mm Screw Retainer Front Stabilizer Roller Arm Bushing Console Large Arm Bearing...
  • Page 32 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Screw Plastic Spacer M8 Locknut M4 x 19mm Self-tapping Screw M6 x 12mm Screw Bumper M10 x 122mm Screw M8 x 20mm Screw M10 Split Washer Tablet Holder Cover Mount Left Pedal Plate M4 x 48mm Screw Left Pedal Handle...

  • Page 33: Exploded Drawing

    EXPLODED DRAWING A Model No. PFEVEL89716.1 R1018A...
  • Page 34 EXPLODED DRAWING B Model No. PFEVEL89716.1 R1018A...
  • Page 35 EXPLODED DRAWING C Model No. PFEVEL89716.1 R1018A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
