Unit: mm
Screen Diag. &
Model Number
View Width (A)
Aspect Ratio
OMS90H2
90" (16:9)
1992
OMS100H2
100" (16:9)
2214
OMS110H2
110" (16:9)
2435
OMS120H2
120" (16:9)
2657
OMS135H2
135" (16:9)
2990
OMS90HR2
90" (16:9)
1992
OMS100HR2
100" (16:9)
2214
OMS110HR2
110" (16:9)
2435
OMS120HR2
120" (16:9)
2657
OMS135HR2
135" (16:9)
2990
Unit: Inch
Screen Diag. &
Model Number
View Width (A)
Aspect Ratio
OMS90H2
90" (16:9)
78.4
100" (16:9)
87.1
OMS100H2
110" (16:9)
95.9
OMS110H2
120" (16:9)
104.6
OMS120H2
135" (16:9)
117.7
OMS135H2
OMS90HR2
90" (16:9)
78.4
OMS100HR2
100" (16:9)
87.1
OMS110HR2
110" (16:9)
95.9
OMS120HR2
120" (16:9)
104.6
OMS135HR2
135" (16:9)
117.7
Note：Data Error be ±1"
The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture modification. Although a manufacturer may offer product advice, it
may be taken or disregarded at the integrator's discretion. Elite Screens will not be held responsible or be otherwise liable for faulty installations.
Updated 5/18/2015 EA
Yard Master 2 Dimensions Table
Left/Right
Frame Length
Frame Height
View Height (B)
Border (A1)
(A2)
(B1)
75
2124
1120
1860
75
2346
1246
1986
75
2567
1368
2108
75
2790
1492
2232
75
3122
1680
2420
75
2124
1120
1860
75
2346
1246
1986
75
2567
1368
2108
75
2790
1492
2232
75
3122
1680
2420
Left/Right
Frame Length
Frame Height
View Height (B)
Border (A1)
(A2)
(B1)
3
83.6
44.1
73.2
3
92.3
49.1
78.2
3
101.1
53.9
83.0
3
109.8
58.7
87.9
3
122.9
66.1
95.3
3
83.6
44.1
73.2
3
92.3
49.1
78.2
3
101.1
53.9
83.0
3
109.8
58.7
87.9
3
122.9
66.1
95.3
Top/Bottom
Bottom of Frame to
Rope Length (B4)
Border (B2)
Ground (B3)
75
590
1917
75
590
2040
75
590
2159
75
590
2280
75
590
2464
75
590
1917
75
590
2040
75
590
2159
75
590
2280
75
590
2464
Top/Bottom
Bottom of Frame to
Rope Length (B4)
Border (B2)
Ground (B3)
3.0
23
75.5
3.0
23
80.3
3.0
23
85.0
3.0
23
89.8
3.0
23
97.0
3.0
23
75.5
3.0
23
80.3
3.0
23
85.0
3.0
23
89.8
3.0
23
97.0
A
A1
A3
Carrying Bag Length
Carrying Bag
Carrying Bag Width
(A3)
Height (B5)
(C)
760
180
240
830
180
240
910
180
240
980
180
240
1090
180
240
760
180
240
830
180
240
910
180
240
980
180
240
1090
180
240
Carrying Bag Length
Carrying Bag
Carrying Bag Width
(A3)
Height (B5)
(C)
29.9
7.1
9.4
32.7
7.1
9.4
35.8
7.1
9.4
38.6
7.1
9.4
42.9
7.1
9.4
29.9
7.1
9.4
32.7
7.1
9.4
35.8
7.1
9.4
38.6
7.1
9.4
42.9
7.1
9.4
Frame/Tube
Width
33
33
33
33
33
33
33
33
33
33
Frame/Tube
Width
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
www.elitescreens.com
