- Page 1 Portable Floor Pull-Up Screen Elite ez Cinema Series FOR MODELS: F60NWV / F72NWV / F84NWV / F100NWV / F84NWH / F100NWH USER’S GUIDE MATTE WHITE Rev. 1.0...
-
Page 2: Parts Identification
PARTS IDENTIFICATION: Front Back Rev. 1.0... -
Page 3: Operational Instructions
Precautions: Warning! Screen damage can result from product mishandling if the enclosed precautions are not followed. In accordance with practicing home fire safety and to avoid screen damage, do not place the screen near or beside a fireplace or high temperature appliances such as a gas stove, BBQ or heater. - Page 4 Open the box cover: Unlatch the buckles on both ends of the box and open the box cover. Next, secure the box with one hand while removing the support rod with your other hand. Installing the support rod: First, make sure that the hanging hook is pointing toward the front facing the same direction as the screen, then insert the square end of the support rod into the support plate as shown below.
- Page 5 Adjusting the screen: Hold the screen with the left hand when the screen has been stretched to the desired position, and then rotate the locking sleeve clockwise with the right hand until the rod is properly locked into position. Screen completely assembled Rev.
- Page 6 Preparing screen for storage 1. Pulling down the screen: First, hold the telescoping support rod with the left hand and loosen the locking sleeve counter-clockwise with the right hand. Then shorten the telescoping support rod slowly into the full retracted position and tighten the locking sleeve to secure it in place.
- Page 7 4. Storing the support rod Properly center the supporting rod in the middle to maintain the weight balance in the box when carrying. 5. Draw the base feet back: Slightly lift each end of the box in turn rotating the two base feet underneath until they are back into alignment with the box.
- Page 8 Elite Screens will either replace or repair the defective unit with a brand new replacement *(see exceptions below) after the defective unit is received and/or confirmed defective. Once the product is received, Elite Screens will send out a new *unit to the customer by ground service (subject to inventory availability).
- Page 9 WO WAY TO REGISTER YOUR WARRANTY WITH LITE CREENS A. On Line (Faster and Easier) www.elitescreens.com/register.html B. Fill out & Fax to (562) 483-8498, Attn: Customer Service Dept. *Your Name: _______________________________________________________ Address: ____________________________________________________________ City/State/Zip ________________________________________________________ *Email Address: ______________________________________________________ *Phone: _____________________________________________________________ *Screen Model: _______________________________________________________ *Serial Number: _______________________________________________________ *Date of Purchase: _____________________________________________________...
- Page 10 Portable Floor Pull-Up Screen Elite ez Cinema Plus Series FOR MODELS: F68XWS1 / F60XWV1 / F84XWV1 / F74XCH1 / F84XCH1 USER’S GUIDE Matte White Rev 1.0...
- Page 11 Precautions: Warning! Screen damage can result from operational errors if the enclosed precautions are not followed. In accordance with practicing home fire safety and avoiding screen damage, do not place the screen near or beside a fireplace or high temperature objects such as a gas stove, BBQ or heater. Place the screen beyond the reach of children.
- Page 12 Operational Instructions: Installation The screen should be installed in an area free of very strong wind and away from any fire activity such as a heater, BBQ grill or fireworks display. 1. Extend base feet: Locate the base feet on the bottom of the box at each end and rotate them until they form right angles.
- Page 13 Putting screen away 1. Retract the screen into case: Press the screen’s handle slowly in a downward motion and allow the screen to retract back gently into the housing. 2. Closing it up: Snap the buckles into place at both ends and verify that the screen’s box is closed securely. 3.
- Page 14 *(see exceptions below) after the DOA unit is received and/or confirmed defective. Once the product is received, Elite Screens will send out a new *unit to the customer by ground service (subject to inventory availability). Should a problem be reported after the 7-day grace period, the item must be shipped to us for warranty repair.
- Page 15 WO WAY TO REGISTER YOUR WARRANTY WITH LITE CREENS A. On Line (Faster and Easier) www.elitescreens.com/register.html B. Fill out & Fax to (562) 483-8498, Attn: Customer Service Dept. *Your Name: _______________________________________________________ Address: ____________________________________________________________ City/State/Zip ________________________________________________________ *Email Address: ______________________________________________________ *Phone: _____________________________________________________________ *Screen Model: _______________________________________________________ *Serial Number: _______________________________________________________ *Date of Purchase: _____________________________________________________...
