Summary of Contents for Safescan 2850
- Page 1 User manual English | Nederlands | Deutsch | Français | Español | Português | Italiano | 繁體中文 | 简体中文 | 日本語 2850 Banknote Counter...
- Page 2 English Introduction Thank you for purchasing a Safescan 2850-S banknote counter. For proper use and maintenance we advise you to read this user manual carefully. Please note Should the equipment be altered in any way or used in a manner...
-
Page 3: Safety Instructions
- To prevent shock hazard, do not touch the power cable with wet hands. - Unplug the device if you want to move it to another position. - Hold the plug when disconnecting the unit from the power outlet, never pull the cord. More info, articles, tutorials and videos at: support.safescan.com... - Page 4 Product overview and box contents Front 1. Control panel 2. LCD touch screen 3. Lever for opening top panel 4. Stacker 5. Hopper 6. Banknote guides 7. Feeding gap adjusting knob More info, articles, tutorials and videos at: support.safescan.com...
- Page 5 12. User manual 9. Power mains connector 13. Dust cover 10. External display connector 14. Power cord 15. Cleaning brush (RJ-12) 11. Update port (USB-A) 16. Cleaning sheets (2x) User Manual 2850-S Banknote Counter More info, articles, tutorials and videos at: support.safescan.com...
-
Page 6: Setting Up Your Machine
5. The device will perform a self test, during which software version number and product number will be displayed. After a successful self-test, the machine will open the count screen and is ready to use. Buttons & touch display batch Count Auto 1200 More info, articles, tutorials and videos at: support.safescan.com... - Page 7 DETECT detection type) Open Batch menu (In BATCH menu: BATCH Loop: 100 - 50 - 25 - 20 - 10 - Off) Automatic start counting On/Off AUTO Open the settings menu MENU More info, articles, tutorials and videos at: support.safescan.com...
- Page 8 Automatic start counting On/Off Add function On/Off (ADD count results of multiple counts to the total.) Open counting speed menu Open detection type menu Button Description Selected batch number Number of counted notes More info, articles, tutorials and videos at: support.safescan.com...
-
Page 9: First Operation
Organise your banknotes in a neat stack, make sure the back of the stack is aligned straight and the notes are centered. More info, articles, tutorials and videos at: support.safescan.com... - Page 10 Remove this note and press [Start/OK] to continue counting. Suspected note 5. On the screen the counting results are shown. Total number of banknotes Sort Auto 1200 UV|MG Detection type More info, articles, tutorials and videos at: support.safescan.com...
- Page 11 Simply press the tile corresponding to the currency or a detection manner you require on the screen for your count. Note: Selecting a detection type will determine the available count modes. More info, articles, tutorials and videos at: support.safescan.com...
- Page 12 MG features. * Polymer (plastic) bank- Piece counting with MG notes often have no detection. MG features. UV | MG Piece counting with both UV + MG detection. 1265 Sort Auto 1200 More info, articles, tutorials and videos at: support.safescan.com...
- Page 13 2. The mode menu contains multiple selection tiles. The active mode type has a blue coloured tile. The available mode types are determind by the active detection type. Simply press a mode type you require for your count. More info, articles, tutorials and videos at: support.safescan.com...
- Page 14 Auto 1200 UV|MG on the touch display below the denomination value. Once you have selected your denomination, the device will automatically multiply the value with the number of counted banknotes. More info, articles, tutorials and videos at: support.safescan.com...
-
Page 15: Add Function
Count results are added to the previous result. Count Auto 1200 Previous count result is cleared when a new count is started. Press to activate Add mode More info, articles, tutorials and videos at: support.safescan.com... -
Page 16: Batch Counting
Note: When the batch number is not reached and there are no more banknotes on the hopper, the device will give 1 sound signal. More info, articles, tutorials and videos at: support.safescan.com... - Page 17 These messages Main error can occur during start up or during Explanation counting. The error Error message message screen number shows the main error, the explanation and solution and the error message number. More info, articles, tutorials and videos at: support.safescan.com...
- Page 18 Use the hopper guides to center the banknotes and when counting a large stack of bank- notes, guide the notes also with your hands during counting. Please refer to first operation. More info, articles, tutorials and videos at: support.safescan.com...
- Page 19 - A banknote with a - Check the banknote LENGTH non-conforming size quality. If no obvious has been detected. visible issues are found, count the banknote again and check if the problem persists. More info, articles, tutorials and videos at: support.safescan.com...
- Page 20 Close the top panel Hopper sensor blocked Remove banknotes and clear dust from the hopper sensor. Stacker sensors are blocked Remove all banknotes from the stacker and clear dust from the stacker. More info, articles, tutorials and videos at: support.safescan.com...
-
Page 21: Quick Menu
2. Press a batch setting. 3. The machine will return to the count screen with the select- ed batch settings activated. Note: Batch presets can be adjusted in counting preferences in the menu. More info, articles, tutorials and videos at: support.safescan.com... - Page 22 2. Press [Use Set-1 or Set-2]. 3. The count menu opens using the saved settings. On the screen, the active indication Set-2 Set-1 or /Set-2 icon appears. Sort Auto 1200 More info, articles, tutorials and videos at: support.safescan.com...
- Page 23 Exit Quick Instruction 1. Press [ESC]. Menu. 2. The machine will return to the count screen. Print / Print Print current Not applicable Serial# count results. (Not available on this model) More info, articles, tutorials and videos at: support.safescan.com...
-
Page 24: Working With The Menu
Keep settings after restart OFF: Switch is grey Round Add- Batch 6. Function switch ON: Switch is bright 1 / 2 white and blue. 7. Page number indication Prev. / Next page More info, articles, tutorials and videos at: support.safescan.com... -
Page 25: Menu Items
(On), the device will only add the count result of completed batches to the total. When the batch number isn’t reached, the machine will ‘correct’ the total to the previous multiple of the set batch amount. More info, articles, tutorials and videos at: support.safescan.com... - Page 26 Versions Setting description Firmware version Shows which firmware version is installed. Software version Shows which software version is installed. More info, articles, tutorials and videos at: support.safescan.com...
-
Page 27: Maintenance And Servicing
Remark: Always power OFF the machine and pull out the power cable from the device before servicing. Opening the top panel and panel Open the top panel using the opening lever under the control panel. More info, articles, tutorials and videos at: support.safescan.com... - Page 28 When using a vacuum cleaner make sure to put a soft brush attachment onto the hose. The device will automatically give maintenance advice. Please make sure to clean the device as advised. Sensors Sensors More info, articles, tutorials and videos at: support.safescan.com...
- Page 29 - When counting errors such as ‘double notes’ or ‘chained notes/ double notes’ occur often, decrease the note thickness distance by turning the adjusting knob anti-clockwise (-). ATTENTION! Make only minor changes at once. Make changes per dot or half a dot. More info, articles, tutorials and videos at: support.safescan.com...
-
Page 30: Software Updates
220 banknotes Power: AC 220-240V / 50-60Hz. Power consumption: 60W maximum Dimensions: (W x D x H) 259 x 254 x 255 mm Weight: 6.4Kgs Operating Temperature: 15-35 °C / 59-95 °F. More info, articles, tutorials and videos at: support.safescan.com... -
Page 31: Technical Support
(GMT +1 timezone) or by e-mail to answer any question you may have regarding the usage of your Safescan device. Visit www.safescan.com for details. When calling or e-mailing our support center, always make sure you have the following information at hand: model number, serial... - Page 32 Safescan B.V. PO Box 7067, 2701AB Zoetermeer, NL Designed in Europe - Made in China www.safescan.com © 2022 Safescan. All rights reserved SAFESCAN® is a registered trademark 20231...
