USER MANUAL
ENGLISH
2985-SX
BANKNOTE COUNTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2985-SX and is the answer not in the manual?

Questions and answers

Related Manuals for Safescan 2985-SX

Summary of Contents for Safescan 2985-SX

  • Page 1 USER MANUAL ENGLISH 2985-SX BANKNOTE COUNTER...

  • Page 3: Safety Precautions

    ENGLISH INTRODUCTION Thank you for purchasing Safescan 2985-SX banknote counter. For proper use and maintenance, we advise to read this user manual carefully. PLEASE TAKE NOTICE Should the equipment be altered in any way or used in a manner for which it was not intended at the time of delivery, the supplier of the equipment accepts no responsibility for injury or damage to personnel or equipment.

  • Page 4: Setting Up Your Machine

    11. Update port (USB-A / SD) 4. TFT touch screen 12. External display connector (RS-232) 5. Reject pocket 13. Print port connector (RJ-10) 6. Stacker 14. Power switch 7. Release handle of top panel 15. Mains power connector 8. Feeding gap adjusting knob www.safescan.com...

  • Page 5: Control Panel

    2. Selected batch number 3. Selected quick menu setting (Set-1/Set-2 or verify) 4. Selected currency setting 5. Add mode on selected 6. Automatic count start selected 7. Selected counting mode 8. Number of counted banknotes 9. Total value of counted banknotes www.safescan.com...

  • Page 6: First Operation

    ENGLISH FIRST OPERATION 1. The Safescan 2985-SX starts by default with the most convenient settings to start a count: Currency: ( - - - ) Currencies that are available on the machine are automatically recognized. Count mode: Mix Counting the value and quantity of both sorted and unsorted denominations.
  • Page 7 3 mixed currencies during the simultaneously. same count. Place banknotes of the preselected currencies on the machine. The results will be shown on the screen. Suspected banknotes and currencies different from the set currencies will be transported to the reject pocket. www.safescan.com...
  • Page 8 UV = Detection of Ultraviolet properties MG = Detection of Magnetic properties SELECTING COUNT MODES 1. Press [MODE] to toggle through the available count modes. 2. The selected count mode is shown in the top right corner of the screen. www.safescan.com...
  • Page 9 Face Sort banknotes per face side. Counting the value and quantity of banknotes sorted per face side and denomination. Banknotes with a different face side or denomination than the first counted banknote are transported to the reject pocket. www.safescan.com...
  • Page 10 Note: This function is not available for all currencies. Count Counting the quantity of banknotes Counting the quantity of banknotes or sheets. without checking size, denomination, face or orientation specifics. www.safescan.com...

  • Page 11: Batch Counting

    • The serial number information is viewed on a receipt print after printing the count results. Printing can be done on the optional Safescan TP-230 printer. • The Safescan 2985-SX also offers the possibility to export the serial number information to the Safescan Money Counting Software.
  • Page 12 If multiple banknotes are transported to the reject pocket, the number 1 banknote is located at the bottom of the stack. 3. The reason for rejection is shown on the right hand side. www.safescan.com...
  • Page 13 See chapter maintenance and servicing. • An incomplete, torn or half-size banknote • Check the banknote quality. HALF BANKNOTE has been detected. If no obvious visible issues are found, count the banknote again and check if the problem persists. www.safescan.com...

  • Page 14: Quick Menu

    With the quick menu opened, press a feature on the screen or press [ESC] to exit the quick menu. Note: Without any action the quick menu screen will return to the count screen within 10 seconds. www.safescan.com...
  • Page 15 Note: Changing the settings will directly disable the Use Set-1 or Set-2. The indication icon will disappear from the screen. Print current count Note: For printing the count results you’ll need the Print results. optional TP-230 printer. www.safescan.com...
  • Page 16 3. Press [START/OK] to activate the menu item. On the screen, the changeable item setting starts blinking. 4. Use [▲▼] to change the available settings. 5. Press [START/OK] to confirm your choice. 6. Press [BACK] to go back 1 step. Press [MENU] to exit the user menu. www.safescan.com...

  • Page 17: User Menu Items

    Disabled (Off): The machine will start with automatic currency detection, count mode Mix and Batch Off. Counting start Enabled (On): The machine will automatically start counting after placing banknotes on the hopper. Disabled (Off): The [START] button needs to be pressed to start counting. www.safescan.com...

  • Page 18: Error Messages List

    ENGLISH ERROR MESSAGES A variety of messages can be displayed on the Safescan 2985-SX. These messages can occur during counting, during start up or described in the ‘Reject list’. The error message screen shows the main problem, the solution and the error message number.

  • Page 19: Maintenance And Servicing

    Back sensors are blocked Open the back panel and remove dust Machine service error Contact Safescan support MAINTENANCE & SERVICING OPENING THE TOP PANEL AND BACK PANEL To ensure continuous reliable operation, regular cleaning of the device’s internal parts and sensors is required.

  • Page 20: Cleaning The Sensors

    ENGLISH CLEANING THE SENSORS 1. Use the enclosed cleaning aids (brush and cleaning sheets) for servicing the 2985-SX. A. Start with brushing the top and bottom surface until all visible dust is removed. B. Use the soft side of a cleaning sheet to wipe all further dust from the top and bottom surface, the sensors and rotation wheels.
  • Page 21 USE IN COMBINATION WITH SAFESCAN MONEY COUNTING SOFTWARE The Safescan 2985-SX can be used in combination with the free Safescan Money Counting Software. Visit: www.safescan.com/downloads. This enables you to export your counting results and serial number information to the PC for further processing.

  • Page 22: Software Updates

    ENGLISH USE IN COMBINATION WITH SAFESCAN TP-230 PRINTER The Safescan 2985-SX can also be used in combination with the optional Safescan TP-230 thermal printer. This enables you to make an instant printout of your counting results. Safescan Safescan printer cable...
  • Page 24 Safescan is a registered trademark of Solid Control Holding B.V. ® No part of this manual may be reproduced in any form, by print, copy or in any other way without prior written permission of Solid Control Holding B.V. Solid Control Holding B.V. reserves all intellectual and industrial property rights such as any and all of their patent, trademark, design, manufacturing, reproduction, use and sales rights.
