  • Page 1 User Manual English 2265 Banknote Counter...
  • Page 2 Click here to open a printable version of the manual in the selected language. Introduction Thank you for purchasing the Safescan 2265 banknote counter. For proper use and maintenance we advise you to read this user manual carefully. Please note...

  • Page 3: Safety Instructions

    - To prevent fire or short circuit, unplug the unit if you want to move it to another position. - Hold the plug when disconnecting the unit from the power outlet, never pull the cord. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 4 English Product overview and box contents Front Back More info, articles, tutorials and videos at: support.safescan.com...

  • Page 5: Setting Up Your Machine

    源線拔下插頭。 rån eluttaget. Dra Thank you for your purchase! Your Safescan 2265 G2 has arrived and is ready to get to work. Simply turn 警告！如果不遵守这些预防措施，可能会导致短路和严重 伤害，如烧伤、触电和火灾危险。 the page and follow the instructions to get started. For more detailed information about the device and its - 如果设备或电源线损坏，切勿使用。...

  • Page 6: Display Overview

    7. Report mode ON 8. Suspect banknote reason & sensitivity level indicator 9. Error alert 10. Value of counted banknotes (only when EUR or GBP is selected) 11. Number of counted banknotes More info, articles, tutorials and videos at: support.safescan.com...

  • Page 7: Buttons And Display

    Adjust time and date & time settings date settings Increase Batch number or Sensitvity level by 1 / Start count report loop (low to high denomination, in mix mode only) / Print More info, articles, tutorials and videos at: support.safescan.com...
  • Page 8 Beep sound on/off MODE Select currency / detection Adjust sensitivity DETECT type settings Batch function on/off / set BATCH batch number Display Selected currency and counting mode Total counted value Number of counted banknotes More info, articles, tutorials and videos at: support.safescan.com...

  • Page 9: Installation

    2. Switch on the device via the power button on the back. 3. Check the currency settings and count your banknotes following the instructions in chapter: 02. Start Counting More info, articles, tutorials and videos at: support.safescan.com...

  • Page 10: First Operation

    English 02. First operation 1. The Safescan 2265 starts by default BATCH START with the following settings: A. Currency: EUR MODE B. Counting mode: MIX DETECT C. Auto start: ON Note: to switch to GBP currency, press [DETECT]. 1. Create a neat and compact...
  • Page 11 Then gently push the banknotes back vertically to start counting. 4. Carefully use your hands to guide the banknotes during the count to avoid them slanting or moving. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 12 5. When the device detects a suspect banknote during counting, it will stop, sound an alarm and display an error message. The last counted banknote in the stacker is the suspect note. Remove this note and press [Start/OK] to continue counting. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 13 [arrow up] or [arrow down] repeatedly to view a detailed count report per denomination. BATCH START START MODE DETECT 10 pieces of 5 Euro counted 3 pieces of 100 Euro counted More info, articles, tutorials and videos at: support.safescan.com...
  • Page 14 English Count modes and detection settings BATCH BATCH START START MODE MODE DETECT DETECT UV+MG None SORT UV+MG None COUNT More info, articles, tutorials and videos at: support.safescan.com...
  • Page 15 Count Counting the num- Counting the number of ber of banknotes or banknotes or sheets without sheets. checking on size. More info, articles, tutorials and videos at: support.safescan.com...

  • Page 16: Batch Counting

    The Batch function is used to create stacks of an equal number of banknotes. The counter will stop when the set batch number has been reached. BATCH BATCH STAR START START MODE MODE DETECT DETECT More info, articles, tutorials and videos at: support.safescan.com...

  • Page 17: Add Function

    English Add function BATCH BATCH START START MODE MODE DETECT DETECT Count results are added to the previous result. Previous count result is cleared when a new count is started. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 18 Number and value are shown. Print Return to count Press [Start/OK] to print count screen results on the optional Safecan TP-230 printer. BATCH BATCH TART STAR START START MODE MODE DETECT DETECT More info, articles, tutorials and videos at: support.safescan.com...
  • Page 19 5. Press START/OK to comfirm the detection level and return to the count screen. BATCH START MODE DETECT Note: Press [CLR] to cancel and return to count screen at any time during this process. More info, articles, tutorials and videos at: support.safescan.com...

  • Page 20: Set Time And Date

    4. When done, press START/OK to save the settings and go back to the count screen BATCH START MODE DETECT Note: Press [CLR] to cancel and return to count screen at any time during this process. More info, articles, tutorials and videos at: support.safescan.com...

  • Page 21: Maintenance

    (recommended: every 1 or 2 weeks). Counting banknotes generates dust which can end up on the sensors. This will influence the functioning of the device. More info, articles, tutorials and videos at: support.safescan.com...

  • Page 22: Cleaning The Device

    3. Follow this procedure for both left (A) and right hand side B). RECOMMENDATION: - Clean the device every 1 or 2 weeks. - Additionally, for optimal maintenance the use of an air duster to remove dust is highly recommended. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 23 English Cleaning cards (option) You can also use the Safescan banknote counter cleaning cards (article no. 152-0663) to clean the roller wheels and magnetic sensors. For more information see www.safescan.com. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 24 (-). - When counting errors like “thickness” (double notes) or “skewed notes” occur, decrease the note thickness distance by turning the sensitivity wheel anti-clockwise (+). More info, articles, tutorials and videos at: support.safescan.com...
  • Page 25 The error concerns the last counted banknote in the stacker. The following messages are possible: More info, articles, tutorials and videos at: support.safescan.com...
  • Page 26 - Clean the sensors and remove any dust that may have acci- dentally blocked the sensors. - If the banknote is in fact genuine, lower the UV sensitivity level and count the banknote again. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 27 - Separate the banknotes if they are - Banknote is stuck together. a suspected counterfeit. - 2 banknotes may be stuck together. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 28 ‘incomplete’ note if it passes the height measuring sensors. Re-count the banknote to see if the problem persists. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 29 Use the hopper guides to center the banknotes. When counting a large stack of banknotes, guide the notes also with your hands during counting. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 30 (EA2 error) and/or that no banknotes startup or other objects are blocking any internal parts of the machine. When the error message remains, contact Safescan technical support for assistance. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 31 Present the note to your bank to have the banknote officiallty assessed. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 32 AC 220-240V / 50-60Hz. Power consumption: max. 60W Dimensions: 29.5 x 25 x 18.4 cm / 11.6 x 9.8 x 7.2 inch Weight: 5.8 kg / 12.8 lbs Operating Temperature: 0 ~ 40°c More info, articles, tutorials and videos at: support.safescan.com...

  • Page 33: Technical Support

    The Declaration of Conformity (DoC) is available at www.safescan.com Take the device to a recycling centre if you want to dispose of it. Never dispose of any electronic devices with household waste. More info, articles, tutorials and videos at: support.safescan.com...
  • Page 34 Safescan B.V. PO Box 7067, 2701AB Zoetermeer, NL Designed in Europe - Made in China www.safescan.com © 2023 Safescan. All rights reserved SAFESCAN® is a registered trademark 20231...
