Summary of Contents for Safescan 2865-S
- Page 1 User manual English | Nederlands | Deutsch | Français | Español | Italiano 2865-S / 2885-S Banknote Counter...
-
Page 3: Safety Instructions
English Introduction Thank you for purchasing a Safescan 2865-S / 2885-S banknote counter. For proper use and maintenance we advise you to read this user manual carefully. Please note Should the equipment be altered in any way or used in a manner for which it was not intended at the time of delivery, the supplier of the equipment accepts no responsibility for injury or damage to personnel or equipment. -
Page 4: Setting Up Your Machine
5. The device will perform a self test, during which software version number and model number will be displayed. After a successful self-test, the machine will open the count screen and is ready to use. More info, articles, tutorials and videos at: support.safescan.com... - Page 5 Add function On/Off (Add count results of multiple counts to the total.) Open counting speed menu Open detection type menu Selected batch number Total value of counted banknotes Number of counted notes More info, articles, tutorials and videos at: support.safescan.com...
-
Page 6: First Operation
The last counted banknote in the stacker is the suspect note. Remove this note and press [Start/OK] to continue counting. Suspected note More info, articles, tutorials and videos at: support.safescan.com... - Page 7 [RIGHT] buttons to toggle between the detection menu pages. Simply press the tile corresponding to the currency or a detection manner you require on the screen for your count. Note: Selecting a detection type will determine the available count modes. More info, articles, tutorials and videos at: support.safescan.com...
- Page 8 UV | MG Piece counting with both UV + MG Select ALL, UV, MG, UV+MG to piece detection. count currencies which are not available on the machine. 3655 Count Auto 1200 UV|MG More info, articles, tutorials and videos at: support.safescan.com...
- Page 9 Counting the value and number Counting the number of banknotes sorted of banknotes while sorting out per denomination. Denominations different any different banknote than the first counted banknote denomination denominations. are rejected. Value Sort Auto 1200 More info, articles, tutorials and videos at: support.safescan.com...
-
Page 10: Add Function
Or repeately press the [BATCH] button to toggle between the presetted batch numbers. - Press [CLR] to clear the entry. - Press [ESC] on the touch screen to exit the batch entry screen. More info, articles, tutorials and videos at: support.safescan.com... - Page 11 3. Press > to scroll through the next result page(s) 4. Press 'Print' to send the count results to a printer. 5. Press <- to exit the report screen and return to the count screen. Total 2.645 Prev. / Next page More info, articles, tutorials and videos at: support.safescan.com...
- Page 12 - A banknote with a non-conforming size has - Check the banknote quality. If no obvious visible WIDTH, LENGTH been detected. issues are found, count the banknote again and check if the problem persists. More info, articles, tutorials and videos at: support.safescan.com...
-
Page 13: Quick Menu
2. Press a batch setting. 3. The machine will return to the count screen with the selected batch settings activated. Note: Batch presets can be adjusted in counting preferences in the menu. More info, articles, tutorials and videos at: support.safescan.com... - Page 14 2. The machine will return to the count screen. Print Print current count Note: For printing the count results you will need the (Print Serial# not results. optional TP-230 printer. available on all models) More info, articles, tutorials and videos at: support.safescan.com...
-
Page 15: Working With The Menu
Enable or disable alarm sounds when an error occurs using the On/Off switch. Batch quantities Change preset batch numbers in quick menu. Currency status Activate and deactivate currencies. Deactivated currencies will not appear during usage. More info, articles, tutorials and videos at: support.safescan.com... -
Page 16: Maintenance And Servicing
Remark: Always power OFF the machine and pull out the power cable from the device before servicing. Opening the top panel and panel Open the top panel using the opening lever under the control panel. More info, articles, tutorials and videos at: support.safescan.com... - Page 17 - When counting errors such as ‘double notes’ or ‘chained notes/double notes’ occur often, decrease the note thickness distance by turning the adjusting knob anti-clockwise (-). ATTENTION! Make only minor changes at once. Make changes per dot or half a dot. More info, articles, tutorials and videos at: support.safescan.com...
-
Page 18: Software Updates
2800-Series banknote counter can keep pace with these changes. All Safescan devices are yearly tested at the Central banks. To make sure your machine is up to date, please check our website regulary to see if there are updates available and needed for your device. -
Page 19: Technical Specifications
If you need any further assistance: our support team is available by phone during office hours (GMT +1 timezone) or by e-mail to answer any question you may have regarding the usage of your Safescan device. Visit www.safescan.com for details. - Page 20 Safescan B.V. PO Box 7067, 2701AB Zoetermeer, NL Designed in Europe - Made in China www.safescan.com © 2020 Safescan. All rights reserved SAFESCAN® is a registered trademark...
