Colorful Technology Website:
http://www.colorful.cn
Thanks for purchasing Colorful series motherboard. This series of motherboards provides excellent performance and quality
assurance.
H310M-D PRO V20/H310M-E PRO V20 motherboard based on Intel H310 Chipset, support Intel LGA1151 Coffee Lake-S
processors, support dual channel DDR4 2133/2400/2666MHz memory, support PCI-E 3.0 standard.
The motherboard provides 1*DVI\HDMI port,1*VGA port,2*DDR4 memory slots,4*SATA3.0 ports,6*USB2.0&4*USB3.0
ports(including the headers),onboard 6-CH audio chipset,onboard 1000M LAN chipset, it' s a Cost-effective motherboard ！
The motherboard provides 1*PCI Express3.0 x16 slot,1*PCI Express x1 slot,it had good extensibility ！
1.1.Packing Contents
1* Colorful H310M-D PRO V20/H310M-E PRO V20 motherboard
2* SATA cables
1* Driver/Utility CD
1* User's Guide
1* I/O shield
1.2.MOTHERBOARD SPEC
CPU
·support Intel LGA1151 Coffee Lake-S processors
Chipset
·Intel H310
Main
・Dual-Channel DDR4 2133/2400/2666MHz support
Memory
·Offer 2 DIMM slots
・1*PCI Express 3.0 x16 slot
Slots
·1*PCI Express x1 slot
Storage
·4*SATA3.0 port
USB
・4*USB3.0+6*USB2.0(including the headers)
・1*PS/2 Mouse or Keyboard port
Rear IO
Connector
・1*LAN(RJ45) port
・4*USB 2.0 ports
・2*USB 3.0 ports
・6-Channel Audio I/O
・1*VGA port
・1*DVI port(only H310M-D PRO have DVI port)
·1*HDMI port(only H310M-E PRO have HDMI port)
H310M-D PRO V20
H310M-E PRO V20
・1*24-pin ATX Power connector
・1* 4-pin ATX 12V Power connector
・1*Front panel audio connector（F_AUDIO）
・1*System panel connector（F_PANEL）
・1*USB2.0 header（F_USB）
Other
・1*USB3.0 header（USB3F）
Connectors
・1*PC speaker connector（BZ）
・1*Case header（CASE）
・1*CMOS jumper（CLR_CMOS）
·2*FANs headers（CPU_FAN，SYS_FAN）
High
・Onboard 6-channel High Definition audio chipset
Definition
·Support 3D surround sound
Audio
・Onboard 1000M LAN
Onboard
LAN
·Provides 10/100/1000Mb Ethernet
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Colorful H310M-D PRO V20
Summary of Contents for Colorful H310M-D PRO V20
- Page 1 Thanks for purchasing Colorful series motherboard. This series of motherboards provides excellent performance and quality assurance. H310M-D PRO V20/H310M-E PRO V20 motherboard based on Intel H310 Chipset, support Intel LGA1151 Coffee Lake-S processors, support dual channel DDR4 2133/2400/2666MHz memory, support PCI-E 3.0 standard.
-
Page 2: Motherboard Layout
1.3.Motherboard Layout 1、PS/2 and USB2.0 ports 2、Connect to VGA monitor 3、Connect to DVI/HDMI monitor 4、Connect to USB3.0 devices 5、Connect to USB2.0 devices and LAN 6、Audio devices 7、4-pin Power connector 8、Fan connector（CPU_FAN，SYS_FAN） 9、Intel LGA1151 socket （Supports Coffee Lake-S Processors） 10、DIMM slots（DDR4） 11、24-pin ATX Power connector 12、SATA3.0 ports 13、PCI Express 3.0 X16 slot, for VGA Card... -
Page 3: Safety Instructions
2.1.Safety Instructions To reduce the risk of fire, electric shock, and injury, always follow basic safety precautions. Remember to remove power from your computer by disconnecting the AC main source before removing or installing any equip- ment from/to the computer chassis. 2.2.Preparing the Motherboard The motherboard shipped in the box does not contain a CPU or memory. -
Page 4: Installing Memory Dimms
The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! 2.3.Installing Memory DIMMs Your new motherboard has 2 slots for DDR4 memory. They support dual channel DDR4 memory technology. There must be at least one memory bank populated to ensure normal operation. -
Page 5: Securing The Motherboard Into The Chassis
2.4.Inslling the Motherboard The sequence of installing the motherboard into the chassis depends on the chassis you are using and if you are replacing an existing motherboard or working with an empty chassis. Determine if it would be easier to make all the connections prior to this step or to secure the motherboard and then make all the connections. - Page 6 2.7.2.Serial ATA 3.0 6Gb/s connectors (7-pin) These connectors connect to Serial ATA 3.0 6Gb/s hard disk drives and optical drives via Serial ATA 3.0 6Gb/s signal cables. 2.7.3.Back Panel IO Connector <Backboard of H310M-D PRO V20> <Backboard of H310M-E PRO V20>...
-
Page 7: Usb 3.0 Connectors
This connector for speakers or headphones. Side R/L(Gray) Side surround speakers connector Onboard VGA, connect to Monitor DVI(H310M-D PRO V20) Onboard DVI port, connect to DVI Monitor HDMI(H310M-E PRO V20) Onboard HDMI port, connect to HDMI Monitor These connectors are for attaching USB devices such as keyboard, mouse, USB Ports or other USB-compatible devices. - Page 8 2.7.6.Front panel audio connector This connector is for a chassis-mounted front panel audio I/O module that supports either High Definition Audio or AC`97 audio standard. Connect one end of the front panel audio I/O module cable to this connector. 2.7.7.System panel connector This connector supports several chassis-mounted functions.
- Page 9 2.7.8.CPU, Chassis, and Power fan connectors (4-pin CPU_FAN, 3-pin PWR_FAN) Connect the fan cables to the fan connectors on the motherboard, making sure that the black wire of each cable matches the ground pin of the connector. 2.7.9.PCI Express3.0 x16 and PCI Express x1 slots The PCI Express x1 slots that are designed to accommodate less bandwidth-intensive cards, such as a modem or LAN card.
- Page 10 2.7.10.Clear CMOS Jumper: CLR_CMOS There is a CMOS RAM on board that has a power supply from external battery to keep the system configuration data. With the CMOS RAM, the system can automatically boot OS every time it is turned on. If you want to clear the system configura- tion, use the CLR_CMOS Jumper to clear data.
-
Page 11: Bios Setup
F9: Optimized Defaults Boot Option #1 F10: Save & Exit ESC/Right Click: Exit 4.Copyright Notice Copyright This motherboard manual belongs to Colorful Technology and Development CO, LTD. No one is permitted to copy, change, or translate without our written permission. -
Page 12: Technical Support
Disclaimer The products name we mentioned in this manual is only for identifying, all of the brands belong to other company. The registered trademarks of IBM, VGA and PS/2 belong to International Business Machines. The registered trademarks of Intel, Pentium, Pentium Ⅱ, Celeron, Pentium III and Pentium 4 belong to Intel. The registered trademark of Athlon belongs to Advanced Micro Devices, Inc.
