Series T90 Axial Piston Pumps
Introduction
Cross section
Slider block
Bushing
Cylinder block
Rear bushing
Charge pump
8 |
©
Danfoss | March 2020
Servo piston
Servo arm
Swash plate
Piston
Slipper
Cradle guide
AX216086485386en-000101
Feedback linkage
Cradle bearing
Roller bearing
Shaft seal
Input shaft
P400621
