INSTALLATION /OWNER'S MANUAL
BI-40-SLIM (BI-S190040-1)
BI-60-SLIM (BI-S190060-1)
BI-88-SLIM (BI-S190088-1)
SAFETY INFORMATION
For your safety, always comply with all
warnings and safety instructions
contained in this manual to prevent
personal injury or property damage.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this appliance.
INSTALLER: LEAVE OWNER'S MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN OWNER'S MANUAL FOR FUTURE REFERENCE.
BI-SLIM SERIES
WARNING
BI-50-SLIM (BI-S190050-1)
BI-72-SLIM (BI-S190072-1)
Version:202210
Advertisement
Table of Contents
Related Manuals for Amantii BI-S190040-1
Summary of Contents for Amantii BI-S190040-1
- Page 1 INSTALLATION /OWNER’S MANUAL BI-SLIM SERIES BI-40-SLIM (BI-S190040-1) BI-50-SLIM (BI-S190050-1) BI-60-SLIM (BI-S190060-1) BI-72-SLIM (BI-S190072-1) BI-88-SLIM (BI-S190088-1) SAFETY INFORMATION WARNING For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. IMPORTANT INSTRUCTIONS ............................FCC CAUTIONS .................................. -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use. -
Page 4: Fcc Cautions
FCC CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Unpacking And Testing The Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components operate correctly. -
Page 6: Bi-40-Slim (Bi-S190040-1)
BI-40-SLIM (BI-S190040-1) This appliance been tested Description Built-in Appliance accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 23.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 7: Bi-50-Slim (Bi-S190050-1)
BI-50-SLIM (BI-S190050-1) This appliance been tested Model Number BI-50-SLIM accordance with the UL Standard 2021 for Voltage 120V AC 60Hz fixed and location dedicated electric room Watts 1500W Max appliances in the United States and Canada. NO HEATER 25.6W If you need assistance during installation, MOTOR HEATER please contact your local dealer. -
Page 8: Bi-60-Slim (Bi-S190060-1)
BI-60-SLIM (BI-S190060-1) This appliance has been tested in accordance Description Built-in Appliance with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances Watts 1500W Max in the United States and Canada. If you need NO HEATER 27.6W assistance during installation, please contact... -
Page 9: Bi-72-Slim (Bi-S190072-1)
BI-72-SLIM (BI-S190072-1) This appliance has been tested in accordance Description Built-in Appliance with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances Watts 1500W Max in the United States and Canada. If you need NO HEATER 28.4W assistance during installation, please contact... -
Page 10: Bi-88-Slim (Bi-S190088-1)
BI-88-SLIM (BI-S190088-1) This appliance has been tested in accordance Description Built-in Appliance with the UL Standard 2021 for fixed and Voltage 120V AC 60Hz location dedicated electric room appliances Watts 1500W Max in the United States and Canada. If you need NO HEATER assistance during installation, please contact MOTOR HEATER... -
Page 11: Safety Drill Screw Area
SAFETY DRILL SCREW AREA There is a safety drill screw area as show below. Please make sure that the fix screws are in this area. Sa fe ty d rill s cre w a re a (Da rk a re a ) OUTDOOR INSTALLATION This electric fireplace is suitable for installation in outdoor areas protected from direct water impingement. -
Page 12: Mantel Clearance
MANTEL CLEARANCE The clearance to the mantel should be 4” minimum when a mantel is applied (Measurement is taken from the trim). Wall (Combustible facing allowed) Mantel Fireplace Fireplace Floor FOR BATHROOM USE If this unit is installed in a bathroom it must be protected by a GIF receptacle or circuit. If If this unit is installed in a bathroom it must be receptacle is used it must be readily accessible. -
Page 13: Hardware Installation
HARDWIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. -
Page 14: Installation
Important note: The optional surround is secured with two screws. Unscrew and lift to remove. It is recommended that two people remove the surround. The rough wall opening size of the fireplace : W(“) D(“) H(“) BI-40-SLIM (BI-S190040-1) BI-50-SLIM (BI-S190050-1) BI-60-SLIM (BI-S190060-1) BI-72-SLIM 73 1/2... - Page 15 2. Remove the framing plates from the unit. framing plate 3. Re-fix the framing plates to the unit as the picture shows. framing plate...
- Page 16 4. Bend up the framing plates. 5. Put the unit into the opening.
- Page 17 6. Drive the mounting screws into the framing plates on the unit and the wall studs. framing plate 7. After checking that the fireplace operates properly, cover the glass panel with protective plastic bag and install plywood or drywall. NOTE: In order to use the supplied trim kit, the thickness of the desired wall finish can not exceed 1 inch.
- Page 18 8. Decorate the plywood or drywall with glazed tile, wallpaper, etc. Fireplace 9. Put back the trim that you’ve removed from the unit at STEP 1. trim...
-
Page 19: Panorama Cover Installation
PANORAMA COVER INSTALLATION Make sure install the pan-cover when the fireplace used in outdoors. Remove the cover from the packaging. The handles will need to be attached to the cover with the provided hardware as shown in fig.1 Fig 1 First, place a plate washer and then a spring washer on the screw as shown in fig.2... -
Page 20: Media Options
MEDIA OPTIONS The media that come with BI-SLIM are large glass nuggets, clear glass, clear and blue & white diamond shaped media. Glass nuggets, clear glass clear and diamond shaped media MEDIA INSTALLATION 1. Take off the front glass. There is a bracket holding the front glass which shows as below. -
Page 21: Operation
OPERATION The Fireplace operates by using either the touch panel located on the upper left hand corner or by remote control. Plug the fireplace into a 15 Amp wall socket. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION Press to turn on and off the fireplace. -
Page 22: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the fireplace is plugged in and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. Each time you press the button, the buzzer inside the unit will beep once. It takes some time for the receiver to respond to the transmitter. - Page 23 AUTO means fireplace can automatically adjust to the temperature you set. When in AUTO, you can set the desired temperature with keys. You can switch temperature between Celsius and Fahrenheit with keys.When it is on Auto mode,fireplace operate at 1500W. Press this button to adjust the speed of the flame.
-
Page 24: Wifi Operation
WIFI OPERATION INSTALL TuyaSmart life There are 2 ways to install TuyaSmart; 1. Search for “TuyaSmart life” in the APP store on your phone, download and install. 2. Scan the QR code below with your mobile phone. WIFI SETTING AND FIREPLACE OPERATION 1. - Page 25 FIG.4 3. Press (flame button) on the touch panel of the fireplace for more than 5 seconds when the fireplace in standby mode. There will be 2 beeps come out from the fireplace and the (flame button) will flash as well indicating that Wi-fi is in EZ mode. Then please confirm to go next.
- Page 26 6. Now you are in the interface like FIG.7. You can operate the fireplace via Wi-fi. FIG.7 NOTE: Turn off the flashing blue Wifi indicator light Touch the (power button) once, the blue light will stop flashing.
-
Page 29: Exploded View
EXPLODED VIEW... -
Page 30: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out Inspect the LED’s and replace them if necessary. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and glowing or dimming replace them if necessary. Appliance turns off and Appliance has overheated and Turn off the main switch, allow... -
Page 31: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:... -
Page 32: Warranty
Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Amantii warrants such products to be free from defects in material and workmanship for a period of five (5) years from the date of the first purchase of such products. - Page 33 The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. GENERAL Amantii reserves the right to make changes at any time without notice, in design, material, specifi cations, prices and the right to discontinue styles and products. GLASS...
