GAS-FIRED, BLOWER MODELS
Blower unit heaters are designed for both heating and ventilating. All Modine gas-fired unit
heater types can be equipped with blowers, including our Hot Dawg
garage heaters and the Effinity
unit heater in North America with this option available.
These units can be used in a variety of ways:
• Ducting air in from adjacent spaces for ventilation.
• Protecting units from corrosive spaces by mounting them remotely and ducting in warm air.
• Where quietness is important, blower fans are lower-noise and can be ducted, unlike
propeller units.
• Deflector hoods can be used in areas with higher mounting heights.
Table 6.1 - Power-Exhausted Blower Unit Model HDB and BDP General Performance Data
Model HDB Sizes
60 75 100
60,000 75,000 100,000 125,000 150,000 175,000 200,000 250,000 300,000 350,000 400,000 150,000 175,000 200,000 250,000 300,000 350,000 400,l000
Btu/Hr Input j
Btu/Hr Ouput j 49,200 61,500 82,000
794- 1140-
Entering Airflow Range (CFM) 635-1111
1389 2116
443-
Outlet Velocity
437-726 546-908
(FPM)
781
Air Temp. Rise (°F) 40-70 40-70 35-65
Max. Mounting
7-13 7-16 8-19
Height (Ft.) k
Heat Throw (Ft.) @ Max Mtg Ht k 20-45 24-57 27-68
Table 6.2 - Separated Combustion Blower Unit Model HDC and BTS General Performance Data
Model HDC Sizes
60 75
Btu/Hr Input j 60,000 75,000
Btu/Hr Ouput j 49,200 61,500
Entering Airflow
635- 794-
Range (CFM) 1111 1389
Air Temp. Rise (°F) 40-70 40-70
Max. Mounting
7-13 7-16
Height (Ft.) k
Heat Throw (Ft.) @
20-45 24-57
Max Mtg Ht k
Table 6.3 - Separated Combusion, High-Efficiency Condensing
Blower Unit Heater Model BTC General Performance Data
Btu/Hr Input j
Btu/Hr Output j
Condensate Production (Gal./Hr.)
Entering Airflow Range (CFM) 2645-4628
Air Temp. Rise (°F)
Max. Mounting Height (Ft.) l
Heat Throw (Ft.) @ Max. Mtg Ht
j Ratings shown are for elevations up to 2,000 Ft. For elevations above 2,000 feet, ratings should be reduced at the rate of 4% for each 1,000 feet
above sea level. (In Canada see rating plate.) Reduction of ratings requires use of a high altitude kit.
k Data taken at 55°F air temperature rise. At 65°F ambient and unit fired at full-rated input. Mounting height as measured from bottom of unit, and
without deflector hoods.
l Data taken at 65°F ambient and unit fired at full-rated input. Mounting height as measured from bottom of unit, and without deflector hoods.
DO NOT LOCATE ANY GAS-FIRED UNIT IN AREAS WITH CHLORINATED,
HALOGENATED, OR ACIDIC VAPORS IN ATMOSPHERE.
Request Catalog 6-189 (HDB, BDP, BTP), 6-175 (BTS) and 6-170 (BTC)
Request Catalog XXX For Complete Technical Information and Specifications.
For Complete Technical Information and Specifications.
