PERFORMANCE AND DIMENSIONAL DATA - MODEL OHP

Table 9.1 - Performance and Dimensional Data
Model Housing
OHP 31
OHP 34
➀ Clearance is 80 in. when heater is fitted with a parabolic reflector.
Figure 9.1 - Unit Dimensional Drawing
Table 9.2 - Clearances to Combustible Materials
Model Sizes BTU'Hr
31,000 (N,P) 31,000
34,000 (N) 34,000
➀ Heaters mounted on an angle between 1° to 30° must maintain clearances posted for 0° or 30°; whichever is greater.
Figure 9.2 - Clearance to Combustibales
10
BTU/Hr input
430 SS 31,000
430 SS 34,000
Mounting
Voltage
Angle
➀
0°
24 vac
30°
0°
24 vac
30°
Recommended Mounting
Ship Weight
Heights
59 lbs 8.0' to 12.0'
59 lbs 8.5' to 13.0'
Side Back
18 N/A
N/A 18
18 N/A
N/A 18
9-123.5
Approx. Area
Heated
➀
8' x 8'
9' x 9'
Top Below End(s)
13 48 12
18 40 12
13 48 12
18 40 12
Control Voltage
24 vac
24 vac
Front
N/A
36
N/A
36
