EVAL-ADXL372Z-M
prevent inserting it backwards and causing damage to the
system.
4. Connect the
ribbon cable.
5. Connect the ISEB to the USB cable.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
User Guide
ADXL372 satellite to the opposite end of the
6. Plug the USB A to Mini-B cable into the PC. If prompted
to install the device, see the Install USB Drivers section for
details regarding how to install and select the correct driver.
The ADXL372 evaluation system is set up and ready to use.
