  • Page 2: Table Of Contents

    12.3. Calibration of the sensor zero ..................7 13. Charging of built-in accumulator battery ................8 14. Warranty policy ........................8 15. Distributors .......................... 8 16. Annex 1. RIFTEK’s measurement devices for railway transport ........11 IMR [Revision 2.0] 7th April 2014...

  • Page 3: Safety Precautions And Measurement Conditions

    Back-to-back distance measuring gauge, IMR Safety precautions and measurement conditions • The metering accuracy depends greatly on the wheel surface quality. There- fore it is necessary to carry out the check and presorting of the wheel surface flaws before measuring the diameter. •...

  • Page 4: Basic Data And Performance Characteristics

    Description Nominal back-to-back distance, mm Nominal back-to-back distance is equal 1590 mm. Example: IMR-1590. Complete set to be supplied Name Quantity Weight, kg The measuring gauge IMR series 1 piece Charger 1 piece Manual 1 piece Case 1 piece Calibration tools (option) on request Design.

  • Page 5: Operation Principle

    Back-to-back distance measuring gauge, IMR Operation principle The method of measurement is based on direct measurement the distance by contactless laser sensor. 10. Working with the gauge 10.1. Gauge turn-on. Press button to turn on the power. The display shows “ErrP” message if the ac- cumulator battery voltage became lower then the control level.

  • Page 6: Gauge Turn-Out

    Back-to-back distance measuring gauge, IMR 10.4. Gauge turn-out The gauge turn-out occurs automatically. The display extinguishes if there were no buttons pressings for 60 seconds, at that only blinking dot is shown. If there were no button pressings for 4 more minutes, the gauge is turned out completely. You can turn the gauge off by long pressing button (more then 3 sec.).

  • Page 7: Get Into Operational Modes

    Back-to-back distance measuring gauge, IMR • Calibration tool RF260.90.000 fig.2; Figure 2 12.2. Get into operational modes • To get into the operational modes it is necessary to turn-off the device (press button more then 3 seconds). • Keeping Green button in pushed position turn-on the device (press but- ton).

  • Page 8: Charging Of Built-In Accumulator Battery

    Back-to-back distance measuring gauge, IMR Figure 3 • If readings of the sensor are sufficiently stable, press the Blue button. Sensor zero position is calculated in the device coordinate system, and prompt ap- pears to save calibration results. Press the Green button to confirm or cancel saving of the results, respectively.
  • Page 9 Back-to-back distance measuring gauge, IMR CHINA CHINA CHINA Zhenshangyou Technologies Shanghai micron-metrology JRKtech Co., Ltd. Co.,Ltd. com., Ltd. 1F, Building 9, 100 Xianlie Rd., Guangzhou, China Rm 2205-2210, Zhongyou Hotel Room 602 unit 4, lane 399, Tel: +86 755 85267190/ 1110 Nanshan Road, Nanshan Mudan road, Pudong New district +86 15989362481...
  • Page 10 Back-to-back distance measuring gauge, IMR ITALY LATVIA, ESTONIA MALAYSIA FAE s.r.l. SIA "SOLARTEX" OptoCom InstruVentures RAILWAY INSTRUMENTS ONLY H-49-2, Jalan 5, Cosmoplex Via Tertulliano, 41 Industrial Park, Bandar Baru Salak 20137 Milano, Italy Duntes 15a, 5th floor, office B7 Tinggi, Sepang, Malaysia Tel: +39-02-55187133 Riga, Latvia Tel: +603 8706 6806...

  • Page 11: Annex 1. Riftek's Measurement Devices For Railway Transport

    Portland, OR, 97210, USA Tel: +1 503 227 7908 Fax: +1 503 223 1258 sales@acuitylaser.com www.acuitylaser.com 16. Annex 1. RIFTEK’s measurement devices for railway transport Laser wheel profilometer. IKP Series A laser profilometer is designed for the measuring of: wheel flange height;...
  • Page 12 Measurements are made directly on rolling stock without wheel set roll-out. Back-to-back distance measuring gauge. IMR Series Gauge is designed for contactless measuring of back-to-back distance of railway, metro and tram wheels in the course of checkup, examination, repair and formation of wheel sets.
