Page 2: Table Of Contents
12.3. Calibration of the sensor zero ................7 13. Charging of built-in accumulator battery ..............8 14. Warranty policy ......................8 15. Distributors ........................ 8 16. Annex 1. RIFTEK measurement instruments for railway transport ......10 IMR [Revision 1.0] 5th November 2010... -
Page 3: Safety Precautions And Measurement Conditions
Back-to-back distance measuring gauge, IMR Safety precautions and measurement conditions • The metering accuracy depends greatly on the wheel surface quality. There- fore it is necessary to carry out the check and presorting of the wheel surface flaws before measuring the diameter. •... -
Page 4: Example Of Item Designation When Ordering
Description Nominal back-to-back distance, mm Nominal back-to-back distance is equal 1590 mm. Example: IMR-1590. Complete set to be supplied Name Quantity Weight, kg The measuring gauge IMR series 1 piece Charger 1 piece Manual 1 piece Case 1 piece Calibration tools (option) on request Design. -
Page 5: Working With The Gauge
Back-to-back distance measuring gauge, IMR 10. Working with the gauge 10.1. Gauge turn-on. Press button to turn on the power. The display shows “ErrP” message if the ac- cumulator battery voltage became lower then the control level. In this case the short-term work is possible after pressing any key. -
Page 6: Indication Parameters Setup
Back-to-back distance measuring gauge, IMR 11. Indication parameters setup 11.1. Image brightness set-up. To change the display brightness it is necessary to: • turn the power on (press button).; • press Blue button and keep it pressed for more than three seconds; •... -
Page 7: Get Into Operational Modes
Back-to-back distance measuring gauge, IMR Figure 2 12.2. Get into operational modes • To get into the operational modes it is necessary to turn-off the device (press button more then 3 seconds). • Keeping Green button in pushed position turn-on the device (press but- ton). -
Page 8: Charging Of Built-In Accumulator Battery
Back-to-back distance measuring gauge, IMR • If readings of the sensor are sufficiently stable, press the Blue button. Sensor zero position is calculated in the device coordinate system, and prompt ap- pears to save calibration results. Press the Green button to confirm or cancel saving of the results, respectively. - Page 9 Back-to-back distance measuring gauge, IMR ITALY FINLAND LITHUANIA FAE s.r.l. TERÄSPYÖRÄ-STEELWHEEL OY JSC "Comexim" RAILWAY INSTRUMENTS ONLY Via Tertulliano, 41 Serbentu, 222, LT-5419 Juvan teollisuuskatu 28 20137 Milano, Italy Siauliai, Lithuania FI-02920 ESPOO, Finland Tel: +39-02-55187133 Tel/Fax:+370 41553487 Tel: +358 400 422 900 Fax: +39-02-55187399 comexim@siauliai.aiva.lt Fax: +358 9 2511 5510...
-
Page 10: Annex 1. Riftek Measurement Instruments For Railway Transport
Fax: 01327 353564 Fax: +1 (518) 449-5567 www.ixthus.co.uk railway_marketing@iem.net info@ixthus.co.uk www.iem.net 16. Annex 1. RIFTEK measurement instruments for railway transport Laser wheel profilometer. IKP Series A laser profilometer is designed for the measuring of: wheel flange height; ... - Page 11 Back-to-back distance measuring gauge, IMR Disc brakes profile gauge, IKD Series Laser disc brakes profilometer IKD Series is designed for disc brakes profile measuring. The main functions of IKD are: obtaining the information on the profile parameters of the working disc brakes surface; ...
