Eclipse
Eight Drawer
11
3
Slide panels [5] down along the grooves between the panels
[3], [4] and [6] as shown.
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
4
6
5
5
12
6
3
A
B
A
B
Attach panel [2] to the unit with 6x dowels (A) and secure
with 6x screws (B). Tighten with a screwdriver.
4
A
B
A
B
B
2
B
B
