Mocka Eclipse Eight Drawer Assembly Instructions Manual page 12

Eclipse
Eight Drawer
21
Drawers x8
M
35
x4
N
N
M
36 3
36
x4
Attach 8x handles (M) to panels [35] and [36] and secure with 16x
handle screws (N). Tighten with a screwdriver.
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
Tighten the
screws 90%..
N
N
Tighten the
screws 90%..
22
35
36
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
35
36
