Mocka Eclipse Eight Drawer Assembly Instructions Manual page 6

Eclipse
Eight Drawer
9
7
Attach panel [4] to panels [7], [8] and [9] with 2x dowels (A) and
secure with 4x locking nuts (D). Tighten with a screwdriver.
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
4
A
D A
D
9
D D
8
D
10
1
A
A
D
D
A
A
7
3
Attach panel [1] to panels [3], [4], [6] and [7] with 6x dowel (A) and
secure with 8x locking nuts (D). Tighten with a screwdriver.
