Summary of Contents for Atlantic VERTIGO 50
- Page 1 VERTIGO electric water heater Enamelled steel tank DOCUMENTATION FOR INSTALLATION AND OPERATION Important: For horizontal installation only The Hot & Cold water outlet must be at the side INDOOR INSTALLATION ONLY 25 Litre Model 40 Litre Model 65 Litre Model 80 Litre Model 9954 –...
- Page 2 Model Max Power Voltage Water output Connections (V~) (B) (W) (Bт) Model 30 (25L) 1000 p. 2/3 p. 4 p. 5 ½” Model 50 (40L) 2250 p. 2/3 p. 4 p. 5 ½” Model 80 (65L) 2250 p. 2/3 p. 4 p.
- Page 3 50 cms minimum...
-
Page 4: Hydraulic Connection
Hydraulic connection (Supplied) PTR Valve (850kPa) Untempered hot water (Kitchen, laundry) Tempered water 50°C (Bathrooms) Cold water Pressure main supply Limiting Valve Non-return and Line Drain lines (350-500 kPa) Isolating Valve Strainer... - Page 5 Warning This device is not intended for use by persons (including children) with physical, sensory or mental disability, or by persons lacking experience or knowledge, unless they have received from a person in charge of their safety adequate supervision or preliminary instructions on how to use the device.
-
Page 6: Cold Water Inlet
Mandatory installation of a safety device in a frost free location (or any other new device which limits the tank pressure) to 850 kPa according to the nominal pressure, with a size of 3/4’’ on the input of the water heater, respecting the local regulations . -
Page 7: Electric Connection
All electrical work must be carried out by a registered electrician and in accordance with AS/NZ 3000. The Atlantic ESWH must be filled with water before connection to a power supply. Switch off the power before removing the cover to avoid any risk of injury or electric shock. - Page 8 safety device or the thermostat. Connect the power supply only via the terminal. replaced by an authorized agent. Failure to respect this clause invalidates the warranty. FLAT 30 FLAT 50, 80, 100...
-
Page 9: Setup And Operation
SETUP & OPERATION - NEVER POWER THE WATER HEATER WITHOUT WATER: Models with an electric heating element will be certainly damaged. - Fill the tank completely. Before powering up, open the hot water taps, drain the pipes in order to empty the air. - Check the tightness of the tubes and of the flange seal under the plastic cover. -
Page 10: Troubleshooting
TROUBLESHOOTING When a malfunction occurs, the user interface of the appliance can display an error code. Fau lt (L E D s tatus) Meaning R emark 2 successive flashes of one shower sign, 3 sec. of pause, 2 successive flashes ... Error 3 : Probe fault Change probe... -
Page 11: Domestic Maintenance
Flushing of sediment and draining To flush or to drain the water heater, power must be turned off and then turn off the cold water supply to the water heater. The lever on the pressure and temperature relief valve should be opened but care should be taken so the lever does not snap back as it could damage the valve seat. -
Page 12: Installation
Installation In accordance with AS/NZS 60335.2.21 the water heaters must be fixed to the ground using the attachment provided and in compliance with the New Zealand Building Code Clause G12, Seismic restraint of storage water heaters. Installation must also comply to AS/NZS 3500.4.2 and all local codes. The clearance required needs to be adequate for service/replacement of cold water inlet piping devices, PTR valve and tempering valves (where fitted), elements and thermostats. - Page 13 No parts (stop valve, pressure reducer, etc.) must be placed between the pressure limiting valve and the cold water inlet of the water heater, apart from a copper pipe. Note: since limited water discharge from pressure limiting valve is normal in the heating operation, the discharge pipe needs be connected to external drain.
-
Page 14: User Maintenance
User Maintenance Operates once a month the PTR valve to prevent scaling and verify that it is not blocked. If this is not done, damage may be caused and the guarantee invalidated. Maintenance by a qualified person Remove the scale sludge. Do not scrape or chip at lime scale deposited on the casing because this may damage the lining Change the magnesium anode every 2 years or when its diameter is less than 10 mm. -
Page 15: Warranty Conditions
NZS 3500 Plumbing & Drainage Code; and NZ G12 New Zealand Building Code – must be complied with by the Installer. The Atlantic ESWH requires a single phase 16 amp supply requiring a licensed electrician for connecting. A licensed plumber must connect cold water and hot water supplies in accordance with this manual. -
Page 16: Warranty Exclusions
• Use of spare parts not recommended by manufacturer. Warranty Exclusions The following warranty exclusions may cause the Atlantic ESWH warranty to become void. This may also incur a service charge and cost for parts should they be necessary. Any physical damage caused by impacts or falls when the ESWH is handled after leaving the factory. - Page 17 (inside), roofs or other losses, directly or indirectly due to leakage from the Atlantic ESWH. Where the Atlantic ESWH has been powered up before it has been filled (heating when dry). Where the Atlantic ESWH has suffered external corrosion due to non-watertight piping connections.
-
Page 18: Warranty
Warranty Water Heater Tank – Domestic 5 years Water Heater Tank – Commercial 2 years Warranty conditions apply: Tank labour – Domestic 2 Years Tank labour – Commercial 1 Year Element 2 Years All Parts and Labour 1 Year... - Page 20 FOR INFORMATION, REPAIRS AND SERVICE NEW ZEALAND: 0800 422 000 For Warranty Registration Register Online: www.atlantic.nz email: info@atlantic.nz...
