VERTIGO
electric water heater
Enamelled steel tank
DOCUMENTATION FOR
INSTALLATION AND OPERATION
Important:
For Horizontal Installation Only
The Hot Water Outlet Must Be
At The Top
INDOOR INSTALLATION ONLY
MODEL 821359
MODEL 831159
MODEL 841258
MODEL 851240
9954 – 1049 NZ
25 Litre
40 Litre
65 Litre
80 Litre
Advertisement
Table of Contents
Related Manuals for Atlantic VERTIGO 821359
Summary of Contents for Atlantic VERTIGO 821359
- Page 1 VERTIGO electric water heater Enamelled steel tank DOCUMENTATION FOR INSTALLATION AND OPERATION Important: For Horizontal Installation Only The Hot Water Outlet Must Be At The Top INDOOR INSTALLATION ONLY MODEL 821359 25 Litre MODEL 831159 40 Litre MODEL 841258 65 Litre MODEL 851240 80 Litre 9954 –...
- Page 2 Model Max Power Voltage Water output Connections (V~) (B) (W) (B ) Model 30 (25L) 1000 p. 2/3 p. 4 p. 5 ½” Model 50 (40L) 2250 p. 2/3 p. 4 p. 5 ½” Model 80 (65L) 2250 p. 2/3 p.
- Page 3 50 cms minimum...
- Page 4 1. Hot water tube 2. Safety relief valve 3. Funnel 4. Pressure reducer recommended if pressure > 0,5 MPa (5 bar) 5. Stop valve 6. Drain to sewage 7. Cold water pipe 8. Dielectric union...
- Page 5 FLAT 30 FLAT 50, 80, 100...
-
Page 6: General Warnings
GENERAL WARNINGS This device is not intended for use by persons (including children) with physical, sensory or mental disability, or by persons lacking experience or knowledge, unless they have received from a person in charge of their safety adequate supervision or preliminary instructions on how to use the device. Children should be supervised to ensure that they do not play with the appliance. - Page 7 6. Installation of a vertical or horizontal wall mounted device: To allow the replacement of the heating element leave a free space of 500mm between the tube ends and the wall or fixed furniture. 7. Switch off the power before removing the cover, to avoid any risk of injury or electric shock.
- Page 8 To drain the device: Switch off the power and the supply of cold water, open the hot water faucets and manipulate the safety valve. To drain under sink water heater disconnect the hydraulic connections and return the device. The products described in this manual are subject to changes at any time to be in accordance with technology and standards.
-
Page 9: Installation
INSTALLATION PRODUCT MOUNTING See “General Warnings” N°.1 to N°.6 For product installation, refer to drawings section 1 page.2 and page 3. HYDRAULIC CONNECTION See “General Warnings” N°.11 to N°.16 For hydraulic connection, refer to drawings section 2 page 4. - It is necessary to clean the supply piping prior to the hydraulic connection. The connection to the hot water outlet is to be carried out with a cast iron or steel sleeve or a dielectric connector, to avoid corrosion of the pipe (direct contact iron / copper). -
Page 10: Setup And Operation
SETUP & OPERATION - NEVER POWER THE WATER HEATER WITHOUT WATER: Models with an electric heating element will be certainly damaged. - Fill the tank completely. Before powering up, open the hot water taps, drain the pipes in order to empty the air. -
Page 11: Troubleshooting
TROUBLESHOOTING When a malfunction occurs, the user interface of the appliance can display an error code. Fault (LED status) Meaning Remark 2 successive flashes of one shower sign, 3 sec. of pause, 2 successive flashes … Error 3 : Probe fault Change probe 2 successive flashes of 2 showers signs, 3 sec. -
Page 12: Scope Of The Guarantee
To claim under guarantee, contact your installer or dealer. If necessary, contact: Atlantic New Zealand - www.atlantic.nz - 0800422 000 - email: info@atlantic.nz Atlantic Australia - www.atlantics.com.au - 03 9852 9599 - email: sales@atlantics.com.au who will inform you of what you should do. The guarantee applies only to examine products which are accepted as faulty by the company underwriting the guarantee.
