Summary of Contents for ACME TV PANEL200
- Page 1 LP-F200 WW 毅丰 LP-F200 CW 2015.09.02 LP-F200 VW 受控正本 User Manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
CONTENTS 1. Safety Introductions ................2 2. Technical Specifications ................ 3 3. How To Set The Fixture ................. 4 3.1 Control Panel .................. 4 3.2 How to Change the “Remote Phosphor Panel” to Change Color Temperature..................5 3.3 Main Function ................. 6 4. -
Page 3: Safety Introductions
1. Safety Introductions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. ... -
Page 4: Technical Specifications
Caution: There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer. Installation: The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. -
Page 5: How To Set The Fixture
3. How To Set The Fixture 3.1 Control Panel 1. DMX IN : For DMX 512 link, use 5-pin XLR cable to link the unit to a DMX controller; 2. DMX OUT: For DMX 512 link, use 5-pin XLR cable to link to the next unit and output DMX signal; 3. -
Page 6: How To Change The "Remote Phosphor Panel" To Change Color
POWER Power On 9. Button: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions 10. Display: hows the various menus and the selected functions; 11. -
Page 7: Temperature
3.3 Main Function To select any of the given functions, press the MENU button up to the required selection as shown on the display. Select the function with the ENTER button and the display will blink. Use the DOWN/UP buttons to change the mode. Once the required mode has been selected, press the ENTER button to confirm. - Page 8 DMX 512 Address To select , press the ENTER button to show DMX ADDRESS on the display. Use the DOWN/UP buttons to adjust the address from 1 to 512. Once the address has been selected, press the ENTER button to setup or automatically exit menu mode without any change after 30 seconds. To go back to the previous functions without any change press the MENU button.
- Page 9 DOWN/UP buttons to select (blackout) or (normal) mode. Once the mode has been selected, press the ENTER button to setup or automatically exit menu mode without any change after 30 seconds. To go back to the functions without any change press the MENU button. Display Inverse To select , press the ENTER button to show DISPLAY on the display.
-
Page 10: How To Control The Unit
To select , press the ENTER button to show SOFTWARE VERSION on the display and the display will show the version of the software of the unit. To go back to the functions press the MENU button. 4. How To Control The Unit You can operate the unit in two ways: 1. -
Page 11: Dmx512 Configuration
4.3. DMX512 Configuration 1 Channel Mode: CHANNEL VALUE FUNCTIONS 3600﹠5200 K 0 ~ 255 0 100% 2 Channel Mode: CHANNEL VALUE FUNCTIONS 3600 K 000 ~ 255 0 100% 5200 K 000 ~ 255 0 100% 4 Channel Mode: CHANNEL VALUE FUNCTIONS... -
Page 12: Dmx512 Connections
140 ~ 181 Slow Open Fast Close 182 ~ 189 Open 190 ~ 231 Slow Close Fast Open 232 ~ 239 Open 240 ~ 247 Random Strobe 248 ~ 255 Open 4.4. DMX512 Connections The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels. 1. -
Page 13: Troubleshooting
5. The end of the DMX 512 system should be terminated to reduce signal errors. 6. 3 pin XLR connectors are more popular than 5 pins XLR. 3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+) 5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4, Pin5 not used. -
Page 14: Fixture Cleaning
6. Fixture Cleaning Cleaning must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: moist, smoky or particularly dirty surroundings can cause a greater accumulation of dirt on the fixture. ... - Page 15 Declaration of Conformity We declare that our products (lighting equipment) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008; EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008. &...
- Page 16 Innovation, Quality, Performance...
