  • Page 1 MEGA STROBE 5000 LED-ST5000 User Manual Please read the user manual before use...

  • Page 3: Table Of Contents

    Table of Contents 1，Safety Information…………………………………………………. 3 2，Rear Panel…………………………………………………………. 5 3，Preparation for Use ………………………………………………...5 4，Main Function …………………………………………………….. 6 5， Remote Control…………………………………………………….11 6， Technical Specification…………………………………………….14...

  • Page 4: 1，Safety Information

    1. Safety Information Warning: This product is for professional use only! It is not for household use. The LED-ST5000 presents risks of lethal or severe injury due to fire and heat, electric shock, ultraviolet radiation, and falls. Flashing light is also known to trigger epileptic seizures in persons who are photosensitive.
  • Page 5 fixture to cool for at least 15 minutes before handling.  Do not modify the fixture or install other than genuine parts.  Do not operate the fixture if the ambient air temperature (Ta) exceeds 40° C (104° To guard against falls ...

  • Page 6: 2，Rear Panel

    2. Rear Panel 1, Power In/Out Circuit Breaker 3. LED display 4, Menu /UP/DOWN/ Enter button 5, DMX signal/ Flash indicator 6, DMX input/output 3. Preparation for Use Table1: Cord cap wirings INSTALLATION The LED-ST5000 may be installed in any orientation. The mounting bracket provides five 12 mm holes for direct fastening or attachment of rigging clamps.

  • Page 7: 4，Main Function

    that, tighten one hand knob to lock the mounting bracket in one end of bracket. 4. MAIN FUNCTION Press MENU button enter the function, then use UP/DOWN or MENU button to select the function you want, final press ENTER button to confirm the function you select.
  • Page 8 If you want back to main menu, please press MENU button. LED display setting Select the LED option, press ENTER button to confirm your selection. You can see the current ON/OFF status of LED display now. You can change its status by press UP/DOWN button.
  • Page 9 Check the version number Select the VER, press ENTER button to confirm. You can see the current version number now (b 10/v 10) and check them by UP/DOWN. Wait for 30 seconds, it will return to main interface. If you want back to main menu, please hold MENU button for 1 second.
  • Page 10 0-255 0-650 ms@50 Hz AC, or 0-530 ms@60 Hz AC Flash duration No flash (single flash with ch. 1) Flash rate 6-255 0.5-25 Hz@50 Hz AC, or 0.6-30 Hz @60 Hz AC 4 Channel Mode Channel Value Function Blackout Flash intensity 6-255 Minimum to maximum 0-255...
  • Page 11 201-255 Random DMX CONTROL SUMMARY Intensity Flash intensity can be set from minimum (blackout) to maximum on 1-channel DMX modes, channel 2 in 2-channel DMX modes and channel 1 in the 3- and 4-channel DMX modes. The maximum intensity can be reduced by selecting low power mode as described Duration Flash duration can be set from 0 to 650 ms on 50 Hz power supplies, or 0 to 530 ms on 60 Hz power supplies, on channel 2 in the 3- and 4-channel DMX modes.

  • Page 12: 5， Remote Control

     Ramp down: Light flashes to full intensity, and then gradually fades.  Ramp up-down: Light gradually increases and decreases.  Lightning: The flashes simulate lightning. Duration is not adjustable.  Random flash: Light flashes randomly with variable rate and intensity. Multiple units flash independently of each other.
  • Page 13  Pin 2 on the Mode DIP switch ON to choose BF-04D function. The optional remote control for BF-04D provides the following:  Slider controls for chase speed and intensity.  Momentary push button control of the blinder effect, when the LED of BLACK OUT is on, that means chase is stop.
  • Page 14 is on when chase stopped and off when chase running. Chase Number Toggle Chase number with Chase button and will be shown on the nixie tube. Chase Mode Toggle Chase running way with MODE button: AUTO/SOUND mode. The corresponding LED indicator will display the selected mode. Blind Effect The blinder effect is controlled with the FULL ON button.

  • Page 15: 6， Technical Specification

    6. Technical Specifications Approved AC power ......100 - 240 V nominal, 50/60 Hz Total Power consumption.
  • Page 16 Innovation, Quality, Performance 15 A...
