EC - Declaration of Conformity
We declare that our products (lighting equipments) comply with the
COLOR BAR
following specification and bears CE mark in accordance with the
provision of the Electromagnetic Compatibility (EMC) Directive
89/336/EEC.
348TC
EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995;
EN61000-4-3: 2002;
EN61000-4-4: 1995; EN61000-4-5: 1995, EN61000-4-6: 1996,
EN61000-4-11: 1994.
&
Harmonized Standard
EN60598-1: 2000+ALL: 2000+A12: 2002
Safety of household and similar electrical appliances
Part 1: General requirements
CB-348TC
User Guide
Professional Entertainment Technology
Innovation, Quality, Performance
19-
Advertisement
Table of Contents
Related Manuals for ACME CB-348TC
Summary of Contents for ACME CB-348TC
- Page 1 EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002; EN61000-4-4: 1995; EN61000-4-5: 1995, EN61000-4-6: 1996, EN61000-4-11: 1994. & Harmonized Standard EN60598-1: 2000+ALL: 2000+A12: 2002 Safety of household and similar electrical appliances Part 1: General requirements CB-348TC User Guide Professional Entertainment Technology Innovation, Quality, Performance...
- Page 2 6. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
-
Page 3: Safety Instruction
h. The address of lightings in the chain will be 1234-1234- (12345678-12345678- ) 1. Safety Instruction 5. Troubleshooting Please read carefully the instruction, which includes important Following are a few common problems that may occur during operation. Here are information about the installation, usage and maintenance. some suggestions for easy troubleshooting: WARNING Please keep this User Guide for future consultation. -
Page 4: Technical Specification
Do not open the unit within five minutes after switching off. 4.6 RC8ch Controller The housing, the lenses must be replaced if they are visibly damaged. Address setting Caution There are no user serviceable parts inside the unit. Do not open the housing or attempt Each time you make a different any repairs yourself. -
Page 5: Control Panel
4.5 DMX512 Connection 3. How To Set The Unit 3.1 Control Panel Display To show the various menus and the selected functions DMX input present MASTER Master Mode SLAVE Slave Mode 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin SOUND Flashing Sound activation... -
Page 6: Main Function
Keep the installation safe. 3.2 Main Function To select any of the given functions, press the MENU button up to when the required one is showing on the display. Select the function by ENTER button and the display will blink. Use DOWN and UP button to change the mode. - Page 8 DMX Address Press the MENU button up to when the DMX Address is showing on the display. Press ENTER button and the display will blink. Use DOWN and UP button to change the DMX512 address. Once the address has been selected, press the ENTER button to store. Back to the main functions without any change press the MENU button (or wait for 8 seconds to exit menu mode).
- Page 9 ENTER button and the display will blink. Use DOWN and UP button to select the on (sound control on) or off (sound control off) mode. Once selected, press the ENTER button to store. 4.4 DMX 512 Configuration Back to the main functions without any change press the MENU button (or wait for 8 Front View: seconds to exit menu mode).
- Page 10 ENTER button to store and g 255 will blink on the display, press UP and Down button to 2-light show adjust the value, press ENTER button to store and b 255 will blink on the display, press UP In slave mode, slave 1 means the unit run as the master unit and slave 2 means 2-light show. and Down button to adjust the value, and press ENTER button to store.
