- Page 1 ORIGINAL INSTRUCTIONS ORBITAL SANDER FPO350B WARNING! PLEASE READ THESE INSTRUCTIONS BEFORE USE THIS MACHINE. BUILDER SAS 32, rue Aristide Bergès-ZI 31270 Cugnaux, France MADE IN PRC...
- Page 2 SAFETY WARNINGS General power tool safety warnings WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"...
- Page 3 f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool.
- Page 4 c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
- Page 5 3, Warning symbol WARNING-To reduce the risk of injury, user must read instruction manual. Always wear ear protection Always wear goggles Always wear a breathing mask In accordance with essential applicable safety standards of European directives 3.1Machine-related safety instructions – Harmful/toxic dust can be produced during your work (e.g. lead-containing paint, some types of wood metal).
- Page 6 if the sward is mixed with paint, polyurethane residue or other chemical materials and the grinding material is hot after long periods of work. – Always use original sanding pads. Foreign pads are not suitable for the speed of the sander and may break. –...
-
Page 7: Your Product
YOUR PRODUCT 1. Technical data Power 350W Mains voltage 230-240V~ 50Hz Speed Max 10000/min Rated Eccentricity: Size of backing pad 150mm Weight Degree of protection IPX0 2. Noise and vibration information Sound pressure level(LPA) 79.7dB(A) Sound power level (LWA) 90.3dB(A) Sound measurement uncertainty K 3dB(A) Vibration emission ah... - Page 8 Figure1 3. Commissioning WARNING Unauthorized voltage or frequency! Risk of accident The mains voltage and the frequency of the power source must correspond with the specifications on the machine's name plate. 4. Operating instructions 4.1 The tool is intended to be operated as a hand held tool. The tool can be used in any position.
- Page 9 4.7 When sanding is finished, turn off the sander by pressing the On/Off key. The sander LED (right) is now turned off. 5. Replacing the sanding pad Always disconnect the power before maintenance! Only use original sanding pad! 5.1 Insert the pad wrench between the backing pad and brake seal to hold the spindle nut.
- Page 10 6. Attaching sanding accessories The suitable sand paper and sanding cloth can be attached quickly and simply to the sanding pad. Press the self-adhesive sanding accessory onto the sanding pad. In the case of a weakening adhesive effect of the sanding paper surface, the sanding pad accessories, in particular those which are not yet touching the work piece, may come loose from the sanding pad and cause injuries.
- Page 11 8. Working with the machine Risk of injury: Always secure the workpiece in such a manner that it cannot move while being machined. 8.1 Observe the following instructions: -The sanding capacity and quality are mainly dependent on the selection of the correct abrasive.
- Page 12 Rubbing or removing excess limestone residue using sanding cloth 6000-7000/min Intermediate sanding of paintwork on stained surfaces Cleaning natural wood window rebate using sanding cloth 4000-6000/min Sanding stained edges Sanding of thermoplastics Maintenance and storage a. Maintenance b. There is no repairs to be provided by the user. For inspection and repair, return the tool directly to a qualified service.
- Page 13 BUILDER SAS ZI, 32 RUE ARISTIDE BERGES – 312070 CUGNAUX – France States that the designated below machine: Product: Orbital sander Model: FPO350B Serial number: 20220133589-20220134188 Developed, designed and manufactured in accordance with the requirements of directives: Machinery Directive 2006/42/EC...
-
Page 14: Warranty
10. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identifed as defective by the designated distributor. -
Page 15: Product Failure
11. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 16: Warranty Exclusions
12. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
