INSTALLATION OVERVIEW AND PARTS LIST
W
I
G
H
2x
X
N
P
L
Lockly Vision Elite can be fitted for both right swing doors and left swing doors.
™
D
E
F
2x
J
K
4x
E
B
A
C
V
R
KEEP THIS CARD!
S
ACTIVATION CARD
T
LOCKLY.COM | HOTLINE: +1(669) 500-8835 | EMAIL: HELP@LOCKLY.COM

Parts List

Labeled As Description
A Keys
B Exterior Assembly
C Exterior
D Mounting Plate
E Adhesive
F PM5×60mm Screw
G Interior Assembly
H PM4*12MM Screw
I Battery Cover
J Deadbolt
K KA4*20MM Screw
Strike Plate
L
N Dust Box
Strike Spacer
P
Vision Connect
R
LAN Cable
S
Power Plug
T
TF Card
U
Activation Card
V
KM3x6mm Screw
W
X Pin Key
U
