Omcan BE-IT-0015A Instruction Manual page 30

Parts Breakdown
Model BE-IT-0015A
Model BE-IT-0030A
Item No. Description
AM183 Nut M6 Inox for 47580, 47581
AM184 Latch Insert KU 15 15 for 47580, 47581
AM185 Screw STEI 6x50 Inox for 47580, 47581
Selflocking Nut M6 Inox. for 47580,
AM186
47581
AM187 Screw TE M6x25 Inox for 47580, 47581
Knob with Pusher M20x1.5 for 47580,
AM188
47581
AM189 Washer D.20 SP.4 for 47580, 47581
AM190 Handle for 47580, 47581
Screw TCEI M8x30 Zinc. for 47580,
AM191
47581
Item No. Description
AM208 Seeger Ring D.16 for 47580, 47581
AM209 Lift Ring Rod for 47580, 47581
AM205 Latch Insert KU 16 15 for 47580, 47581
AM183 Nut M6 Inox for 47580, 47581
AM210 Nut M8 Inox for 47580, 47581
AM186 Selflocking Nut M6 Inox for 47580, 47581
Item No. Description
AM210 Nut M8 Inox for 47580, 47581
AM220 Washer D.8 Inox for 47580, 47581
AM222 Screw TE M8x30 Inox for 47580, 47581
AM223 Latch Insert KU 40 15 for 47580, 47581
47580
47581
Position Item No. Description
Automatic Head Support for 47580,
1 AM192
47581
2 AM193 Key 8x7x30mm for 47580, 47581
Screw TCEI M10x30 Zinc. for 47580,
3 AM194
47581
4 AM195 Screw STEI M6x6 for 47580, 47581
5 AM196 Head Pin D.15x38 for 47580, 47581
6 AM197 Washer D.6 for 47580, 47581
7 AM198 Nut M6 Zinc. for 47580, 47581
8 AM199 Gas Spring D.6 C=100 for 47580, 47581
Screw TCEI M6x20 Zinc. for 47580,
9 AM200
47581
Position Item No. Description
1 AM211 Screw STEI M610 for 47580, 47581
2 AM185 Screw STEI M6x50 Inox for 47580, 47581
3 AM212 Sliding Shoe 12x12x45 for 47580, 47581
4 AM213 Lever Lift Ring for 47580, 47581
5 AM214 Spring for 47580, 47581
7 AM215 Pin Lever Lift Ring for 47580, 47581
Position Item No. Description
1 AM224 Latch Insert KU 20 15 for 47580, 47581
Screw TCEI M10x45 Inox for 47580,
2 AM225
47581
3 AM226 Screw TCEI M8x20 Zinc for 47580, 47581
4 AM227 Head Plate for 47580, 47581
Knife Support Group
Position Item No.
10 AM201
11 AM202
12 AM203
13 AM204
14 AM205
15 AM206
16 AM207
17
18
Operate Ring Group
Position Item No.
8 AM216
9 AM217
10 AM218
11 AM219
12 AM220
13 AM221
Position Item No.
5 AM228
6 AM229
7 AM230
8
30
Description
Screw TCEI M6x30 Zinc. for 47580,
47581
Head Stop for 47580, 47581
SX Support for 47580, 47581
DX Support for 47580, 47581
Latch Insert KU 16 15 for 47580, 47581
Latch D.10x20 for 47580, 47581
Knife Support Group for 47580, 47581
Description
Pin Ring Lever for 47580, 47581
Plug D.8x30 for 47580, 47581
Screw TE M8x35 Inox for 47580, 47581
Selflocking Nut M8 Inox for 47580,
47581
Washer D.8 Inox for 47580, 47581
Operating Ring Group for 47580, 47581
Head Plate Group
Description
Rod Guide D.16x180 for 47580, 47581
Screw TCEI M10x45 Zinc for 47580,
47581
Head Plate Group for 47580, 47581
Position
19
20
21
22
23
24
Position
15
16
17
18
19
Position
9
10
