Omcan BE-IT-0015A Instruction Manual page 32

Parts Breakdown
Model BE-IT-0015A
Model BE-IT-0030A
Item No. Description
AM220 Washer D.8 Inox for 47580, 47581
AM183 Nut M6 Inox for 47580, 47581
AM197 Washer D.6 Zinc for 47580, 47581
AM186 Selflocking Nut M6 Inox for 47580, 47581
AM258 SX Bracket for 47580, 47581
AM259 DX Bracket for 47580, 47581
AM260 Spring for 47580, 47581
Screw TCEI M6x25 Inox for 47580,
AM261
47581
Item No. Description
AM274 Selflocking Nut M8 Inox for 47580, 47581
AM275 Roller Support for 47580, 47581
Item No. Description
AM280 Pin for 47580, 47581
AM281 Seal OR 6200 for 47580, 47581
Screw TSPEI M6x12 Zinc for 47580,
AM282
47581
AM283 Ring for 47580, 47581
47580
47581
Position Item No. Description
1 AM219 Selflocking Nut M8 Inox for 47580, 47581
Washer TTQ M5x16 Inox for 47580,
2 AM262
47581
3 AM263 Washer D.5 Inox for 47580, 47581
4 AM264 Safety Protection Carter for 47580, 47581
5 AM265 Frame Protection Carter for 47580, 47581
6 AM266 Washer for 47580, 47581
7 AM267 Selflocking Nut M5 Inox for 47580, 47581
Screw Poeliers M8x30 Inox for 47580,
8 AM268
47581
Position Item No. Description
1 AM276 Screw TE M8x110 Inox for 47580, 47581
Screw TSPEI M6x12 Inox for 47580,
2 AM277
47581
Position Item No. Description
1 AM220 Washer D.8 Inox for 47580, 47581
2 AM284 Stopper for 47580, 47581
3 AM285 Screw TE M8x45 Inox for 47580, 47581
4 AM286 Screw TE M8x20 Inox for 47580, 47581
Rounding Safety Group
Position Item No.
9 AM187
10 AM269
11 AM270
12 AM271
13 AM272
14 AM273
15
16
Roller Support Group
Position Item No.
3 AM278
4 AM279
Rounding Plate Group
Position Item No.
5 AM287
6 AM288
7 AM289
8
32
Description Position
Screw TE M6x25 Inox for 47580, 47581 17
Screw TE M6x45 Inox for 47580, 47581 18
Screw TE M8x12 Inox for 47580, 47581 19
Screw TCEI M6x30 Inox for 47580,
20
47581
Screw TCBEI M6x8 Inox for 47580,
21
47581
Rounding Safety Group for 47580,
47581
Description Position
Roller for 47580, 47581 5
Roller Support Group for 47580, 47581
Description Position
Stopper for 47580, 47581 9
Rounding Plate for 47580, 47581 10
Rounding Plate Group for 47580, 47581
