Omcan BE-IT-0015A Instruction Manual page 33

Model BE-IT-0015A
Model BE-IT-0030A
Item No. Description
AM290 Screw TE M8x16 Zinc for 47580, 47581
AM291 Latch Insert KU 12 15 for 47580, 47581
AM292 Bearing NTN 6205 2RS for 47580, 47581
Washer D.10x30 SP. 5 Zinc for 47580,
AM293
47581
AM294 Cam Scrolling Flange for 47580, 47581
AM295 Top Pin D.8x70 for 47580, 47581
AM195 Screw STEI M6x6 for 47580, 47581
AM296 Cam Control Pin for 47580, 47581
AM297 Washer for 47580, 47581
Item No. Description
AM315 Sliding Trolley for 47580, 47581
AM316 Shoe Guide for 47580, 47581
Sliding Sleeve with Spheres for 47580,
AM317
47581
Item No. Description
Motor KW 0,55 6 POLI B3 220/380/60
AM322
UL/CSA Three Phases for 47580, 47581
AM323 Screw TE M8x25 Zinc for 47580, 47581
AM324 Motor Pin for 47580, 47581
AM325 Seeger Ring D.18 for 47580, 47581
47580
47581
Position Item No. Description
1 AM298 Bearing NTN 6204 2RS for 47580, 47581
2 AM299 Washer D.8x24 SP. 4 for 47580, 47581
3 AM300 Screw STEI M4x6 for 47580, 47581
4 AM301 Lower Pin D.8x23 for 47580, 47581
5 AM302 Latch Insert KU 08 08 for 47580, 47581
6 AM303 Connecting Rod for 47580, 47581
7 AM304 Seeger Ring D.47 for 47580, 47581
8 AM305 Cylinder Flange for 47580, 47581
9 AM306 Bearing NTN 6008 2RS for 47580, 47581
Position Item No. Description
1 AM197 Washer D.6 Zinc for 47580, 47581
2 AM318 Screw TCEI M6x16 Zinc for 47580, 47581
3 AM319 Pin Holder for 47580, 47581
Position Item No. Description
1 AM326 Motor Fixing Shelf for 47580, 47581
Threaded Bar M8x85 Zinc for 47580,
2 AM327
47581
3 AM328 Nut M8 Zinc for 47580, 47581
4 AM239 Nut M8 Zinc for 47580, 47581
Parts Breakdown
Automatic Pulley Group
Position Item No.
10 AM307
11 AM308
12 AM309
13 AM310
14 AM311
15 AM312
16 AM313
17 AM314
18
Sliding Trolley Group
Position Item No.
4 AM320
5 AM321
6
Position Item No.
5 AM299
6 AM329
7
8
33
Description Position
Bearing NTN 6009 2RS for 47580,
19
47581
Flange for Pulley for 47580, 47581 20
Seeger Ring D.40 for 47580, 47581 21
Latch Insert KU 25 20 for 47580, 47581 22
Pin Holder D.12x150 for 47580, 47581 23
Pulley for 47580, 47581 24
Screw TCEI M10x35 Zinc for 47580,
25
47581
Automatic Pulley Group for 47580,
47581
Description Position
Screw STEI M8x35 for 47580, 47581 7
Sliding Trolley Group for 47580, 47581
Motor Group
Description Position
Washer D.8x24 SP. 4 for 47580, 47581 9
Motor Group for 47580, 47581
