Default Login - LEGRAND Server Technology PRO4X Quick Setup Manual

▶
To make a wired connection:
1. Connect a standard network patch cable to one or both Ethernet ports on the PDU.
• If one Ethernet port is higher speed, use the higher speed port for network connection. •
2. Connect the other end of the cable to your LAN.
Sample iX9 controller. Port locations may vary by model.
Warning: Accidentally plugging an RS-232 RJ-45 connector into the Ethernet port can cause permanent damage(s) to the
Ethernet hardware.

Default Login

User Name: admin
Password: legrand
Choose Initial Configuration Method
Depending on your networking environment, choose the best method to initially configure your PRO4X.
• •
Using a computer:
• •
Using a mobile device:
• •
Using the command line interface:
Initial Configuration in a Web Browser
After connecting to a DHCP IPv4 network, an IPv4 address is automatically assigned to your PDU.
The IP address is available using the front panel display.
1. Press the X or O button to go to the Main Menu.
2. Use the arrow buttons to scroll to Device Info, then press O.
3. Use the arrow buttons to scroll through the information and view the IP address.
4. In a web browser, enter the IP address and log in with the default user credentials. If any security alert messages
display, accept them.
A password change is enforced at first login.
PRO4X Quick Setup Guide | SPDU_G4_QSG_B1_4.0.40
255-92-0001-00
Initial Configuration in a Web Browser
Initial Configuration with PDView App
Initial Configuration with CLI
(on page 8).
(on page 9).
(on page 9)
page
8
