Quick Links
2 P+E socket outlets - French/Belgian standard
IP 66 - IK 08
VEHICLE MANUFACTURER DETAILS
Check with your vehicle manufacturer for availability of a charging cable compatible
Cord
Standard
Cord
Standard
Scooters, quad bikes and light vehicles up
to 8 A
Technical data sheet: F01398EN/05
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex
Tel: 33(0)5 55 06 87 87 - Fax: 33(0)5 55 06 88 88
www.legrand.com
with the Green'up system.
cord
cord
0 904 71
Updated: 14/03/2023
Cat. No(s): 0 904 71 - 0 904 75 - 0 904 76 - 0 904 78
INSTALLER DETAILS
Dedicated line
(1)
with 30 mA
2.5 to 6 mm
2
type F (HPi), 20 A
single phase RCBO
The earth
measurement
must be
checked
(1)
To be carried out by a professional electrician.
(2)
Charging time varies according to vehicle model.
0 904 78
100
Indicative
(2)
charging time
for 14 kWh/100 km:
3 h 45
100
Indicative
charging time
for 14 kWh/100 km:
6 h 00
Created: 06/10/2011
1/4
