Threaded Grounding Point
The primary means of earthing the product is via the power cord connected to an earthed receptacle; however, some
models have a supplementary, threaded grounding point for connection to TT earthing systems or where required by the
Authority Having Jurisdiction (AHJ) per national, regional or local applicable electric codes.
Identify it via the grounding symbol:
Where required, wire this point to an electrical system to protectively ground the PRO4X.

Connecting the PDU to a Power Source

Do not stretch the power cord.
To connect a PDU to the power source:
1. Verify that all circuit breakers on the PRO4X are set to ON. If not, turn them ON.
Or make sure that all fuses are inserted and seated properly. If there are any fuse covers, ensure that they are
closed.
Note: Not all models have overcurrent protectors.
2. Connect each PRO4X to an appropriately rated branch circuit. Refer to the label or nameplate affixed to your PRO4X for
appropriate input ratings or range of ratings.
3. When a PRO4X powers up, it proceeds with the power-on self test and software loading for a few moments. At this
time, the outlet LEDs cycle through different colors.
Note: If a PDU beeps after being powered up, either its circuit breaker has tripped or the L-N wiring is reversed. If no circuit
breakers tripped, check the wiring of the plug adapter that is used or the direction in which the plug or plug adapter is
plugged into the power socket.
4. When the software has completed loading, the outlet LEDs show a steady color and the front panel display illuminates.

Connecting to Your Network

To remotely administer the PRO4X, you must connect it to your local area network (LAN).
Ethernet port is enabled by default. Port layouts and number of Ethernet ports vary by model.
PRO4X Quick Setup Guide | SPDU_G4_QSG_B1_4.0.40
255-92-0001-00
