- Page 1 Pandora would like to thank you for choosing our DXL 1100L service and security system...
- Page 2 «Experimental Engineering Factory» The device was developed by a group of Russian engineers with the highest INSTALL PANDORA DXL 1100L USING INSTALLATION SCHEME IN THIS MANUAL qualification. It includes a number of highly advanced and unique technological, AND ALARMSTUDIO SOFTWARE.
-
Page 3: Table Of Contents
Arming procedure Programming using VALET button Disarming procedure Vehicle search function Additional information PANIC mode Warranty obligations Remote and automatic engine start Installation certificate System settings menu Acceptance certificate Vehicle status control Warranty card PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 4: Base Unit
• Built-in integral accelerometer for determining motion and shocks with adaptive Security zones processing algorithm and sensitivity controls. Pandora DXL 1100L service-security system guards following independent zones • Built-in back-up battery with corresponding zone notifications on the remote and recording alarms into the •... -
Page 5: System Set
OLED SEND/ALARM Power saving mode 2. The system goes to this mode 10 day (you can set the time display indicator interval using AlarmStudio) after last arming/disarming. This mode reduces energy consumption by 50%. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 6: Meaning Of The Remote Control Led Indicator
REMOTE CONTROL IS UNIFIED CONTROL DEVICE. REMOTE CONTROL sound confirmation (1 sec) FUNCTIONS DEPEND ON SECURITY SYSTEM MODEL Switch off the ignition Switch off ‘Ignition during remote or maintenance’ mode automatic engine start (>2 sec.) procedure. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 7: Icons Of The Remote Control
«Motion sensor» Battery level security zone 0° «Tilt sensor» Engine temperature security zone Alarm clock «Ignition» security zone Engine operation icon «Trunk» security zone Engine is started «Clutch», «Brake» Engine is stopped security zone srop PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 8: Replacing A Battery In The Remote Control
Each pressing will be confirmed with orange LED indicator flash. After external VALET button and indicated by flashes of the external LED indicator. correct enter of the fourth digit the system will be disarmed. The correct input will be PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 9: Arming Procedure
4 times, and turn signals will flash 4 times, the remote will sound «WARNING» ringtone (after «DISARMING» ringtone) and will indicate zones triggered. All recent alarm events can be viewed in the event history. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 10: Remote And Automatic Engine Start
Engine operation duration depends on system settings – either heating time or threshold temperature for engine stop To remotely stop the engine while it performs heating, press and hold button for 2 or more seconds. The engine will be PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 11: System Settings Menu
• maintenance mode of the vehicle 1 2 3 connect. lost: management no sound valet mode 14 45 siren enabled settings • siren signals adjusting • time setting 06 30 valet mode siren disabled PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL settings... -
Page 12: Vehicle Status Control
Wire «7» (Purple) (CH5+) — Factory setting is «Siren». It connects to siren control channel 1 2 3 wire (+) (maximum load current is 2A). This output is multipurpose, it can operate in management accordance with selected logic. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 13: Wiring Diagram
Pandora DX model: DXL1100L WARNING! IT IS FORBIDEN TO SHIELD THE BUILT-IN ANTENNA! PLACE THE BASE UNIT AS FAR AS POSSIBLE FROM METAL SURFACES Wiring diagram IT IS FORBIDEN TO REMOVE ORIGINAL FUSES! IT IS FORBIDEN TO INSTALL THE SYSTEM WITH DEMAGED CABLES! -
Page 14: Automatic Engine Start Settings
It is required for implementing remote start function, ignition maintenance and for in series (incut) connection of the ignition. A negative output of additional channel with maximum load current 200mA. This channel is universal and can operate in accordance with selected logic. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... - Page 15 80° start temp send settings send settings 80° start temp – 20° work duration – 20° work duration – 20° минут минут PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL start temp send settings start temp...
-
Page 16: Sensors Settings
датчик удара включен включен тревож. уров. доп. датчик включен increase adjusting decrease датчик удара shock sensor датчик удара предвар. уров. предвар. уров. warn. lvl. = датчик удара включен PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL включен предвар. уров. датчик удара включен... -
Page 17: Siren Signal Settings
1 sec. to save sounds disabled To exit menu, press and hold button for 1 second. To exit menu, press and hold button for 1 second. sounds enabled sounds enabled PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL sounds enabled... -
Page 18: Remote Control Sound Notifications Settings
This mode does not require to save. when ignition is switched on. To exit this mode, select Valet mode and shortly press To exit menu, press and hold button for 1 second. button. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 19: Maintenance Mode
06 30 14 45 hours minutes This mode does not require to save. 06 30 To exit menu, press and hold button for 1 second. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 20: System Configuration And Programming
Pauses between presses should not exceed 1 Short orange lights The number of recorded remotes control second. Each pressing will be confirmed with orange LED indicator flash. The correct PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 21: Updating Firmware
To program using a computer, you Enter programming mode by entering «Service PIN-code», Use VALET button to need a standard USB cable, a computer with Windows XP/ Vista/7/8/10 and Pandora enter the desired level number (press the button a number of times, equal to level AlarmStudio application (you can download it from pandorainfo.com). - Page 22 Level 3 – Recording idle speed To timely turn off the starter during automatic or remote engine start via analog tachometer input, it is necessary to record the engine idle speed. PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL...
-
Page 23: Additional Information
CERTIFICATE AND VARRANTY CARD BY INSTALLER. THESE half ) years since the moment of production. DOCUMENTS MAY BE REQUIRED FOR CONTACTING CUSTOMER SUPPORT. This warranty does not include batteries of the remotes, as they have their own PANDORA DXL 1100L SERVICE-SECURITY USER MANUAL... -
Page 24: Installation Certificate
Car specifications: Car model____________________________________________ Type _____________________ Id number (VIN)_________________________________________________________________ Registration number_____________________________________________________________ Security system specification: MODEL PANDORA DXL 1100L Serial number______________________________ Service center name, full address and installer’s stamp ______________________________________________________________________________ ______________________________________________________________________________ Signature_____________________/___________________________________/ Signator... -
Page 25: Acceptance Certificate
A D D I T I O N A L I N F O R M A T I O N ACCEPTANCE CERTIFICATE Pandora DXL 1100L is in conformity with Electromagnetic Compatibility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number ______________________________ Date of production___________________ Responsible person’s signature (stamp)
