Installation instruction of Pandora DXL service-security system
with integrated CAN-bus adapter
for NISSAN QASHQAI (2014-)
model code 2335
This instruction has the status of a recommendation
contact@pandorainfo.com
pandorainfo.com
Pandora DXL
NISSAN QASHQAI (2014-)
1
Advertisement
Related Manuals for Pandora DXL 2335
Summary of Contents for Pandora DXL 2335
- Page 1 Pandora DXL NISSAN QASHQAI (2014-) Installation instruction of Pandora DXL service-security system with integrated CAN-bus adapter for NISSAN QASHQAI (2014-) model code 2335 This instruction has the status of a recommendation contact@pandorainfo.com pandorainfo.com...
- Page 2 Pandora DXL NISSAN QASHQAI (2014-) Placing units (modules) and connections Pandora base unit can be placed and main connections can be performed behind the steering wheel. RF-module location Base unit location Main points of connection Readable statuses, commands that are performed via CAN1-bus...
- Page 3 Pandora DXL NISSAN QASHQAI (2014-) Removing plastic panels to install and connect Remove plastic panel under the steering wheel to access BCM unit. Unscrew two screws and remove the panel. This instruction has the status of a recommendation contact@pandorainfo.com pandorainfo.com...
- Page 4 Pandora DXL NISSAN QASHQAI (2014-) Connect to CAN-bus Twisted pair cable of CAN-bus is in the wiring of BCM unit behind the dashboard or in OBD II diagnostic socket. blue pink Connection: orange-white to blue (CAN-H). orange-black to pink (CAN-L).
- Page 5 Pandora DXL NISSAN QASHQAI (2014-) Installing Pandora base unit Base unit can be placed behind the dashboard or on the BCM unit. To do it use plastic ties and double sided adhesive tape. Fixing the base unit in this location allows you to fine-tune the sensitivity of the built-in shock and motion sensors.
- Page 6 Pandora DXL NISSAN QASHQAI (2014-) Connecting autostart (START/STOP button). All connections are performed in the BCM unit. Ignition 1, controlled by negative potential Starter, controlled by negative potential This instruction has the status of a recommendation contact@pandorainfo.com pandorainfo.com...
- Page 7 Pandora DXL NISSAN QASHQAI (2014-) Connecting autostart (mechanical key). All connections are performed in the BCM unit Ignition 1, gray wire (controlled by negative potential) Starter, green wire (controlled by negative potential) This instruction has the status of a recommendation contact@pandorainfo.com...
- Page 8 Pandora DXL NISSAN QASHQAI (2014-) Bypass settings Select the desired model code. For correct operation, the model code must be correctly selected. Apply the next settings in Pandora Alarm Studio: 1. Select 2.3.3 "Bypass via CAN" option. Menu Submenu Function...
- Page 9 1. Connect the system to a PC using a USB cable. The PC must have Windows (XP, 7, 8, 10) and Internet connection. Enter the programming mode. 2. Run Pandora AlarmStudio, login to the system. Confirm the sending data to the server. After that, data will send to the server and cloning procedure will be performed. The procedure usually takes up to 4 min.
-
Page 10: Additional Connections
Pandora DXL NISSAN QASHQAI (2014-) Additional connections. To control ignition, connect analog input. Contact #8 of OBD II diagnostic socket or socket on the fuse box (it is necessary to enable keyless immobilizer bypass function and engine blocking via CAN. - Page 11 Pandora DXL NISSAN QASHQAI (2014-) Installing siren Install the hood trigger on the radiator frame. Install the siren on the radiator frame using screws, connect to the system. This instruction has the status of a recommendation contact@pandorainfo.com pandorainfo.com...
