TKO 522DBS Owner's Manual page 9

Assembly
ASSEMBLY INSTRUCTIONS
Note: Clean up an area at least 6' by 6' and a ceiling height of 7'3" high.
Before starting assembly remove all parts and hardware from the
carton and ensure you have everything according to the list.
Do not tighten nuts and bolts until you have completed all the
assembly
STEP 1.
Place Center Base Frame (2), the Left (1L) and Right (1R) Base Stabilizers on the floor as shown.
Align the Base Stabilizers with the first set of holes of the Center Base as shown. Use two Hex
Bolts (23), four Washers (21), and two Nylon Locknuts (22) to secure. If not pre-installed, insert
the Round Foot Cap (17) into the end of each Base Tube.
PLEASE DO NOT RETURN TO STORE, CALL OUR CUSTOMER SERVICE DEPARTMENT
FIRST AT 1-866-856-3488 or 713-895-9270
steps.
