Access Point Installation
2. Bring the LAN cable from the wall through the bracket hole.
Align the cable before attaching the bracket to the wall.
3. Attach the wall bracket to the wall using three M3.5 screws and three screw-in
anchors.
4. Align the access point red dot against the three red dots on the -WL bracket.
5. Press and rotate the access point clockwise about one-sixth turn until it locks into
place on the bracket.
6. Attach the network cable.

Install the Access Point on a Silhouette Ceiling

Before You Begin
You need the following items:
•
AP3000
•
AH-ACC-BKT-AX-SL bracket
About This Task
You can mount the access point to a ceiling grid with 1/8 in. or 1/4 in. bottom opening.
Silhouette is an Armstrong Ceiling Solutions name.
Note
A standard Ethernet cable can be used if you do not mind the cable being
visible. To hide the Ethernet cable, a flat cable and a cable cap is required.
ExtremeWireless™AP3000 Access Point Installation Guide
Install the Access Point on a Silhouette Ceiling
23
