2-9.4 Chassis Panel Connectors
A.
B.
E.
F.
A : PS/2 Mouse
B : LAN Port RJ45 (85DIR3-L
only)
C : LPT1 Port
D : GAME/MIDI
E : PS/2 Keyboard
F : USB 1 (underside)
2-9.5 LAN Connector RJ45 (85DIR3-L only)
One RJ45 connector is on board for networking connection and also
provides support for Wake On LAN function.
Yellow LED "On" to indicate
Network hub is in connection
with the system.
RJ45 Connector
C.
G.
H.
F : USB0 (middle)
G : COM1
H : COM2
I
J : Line In/
K : Microphone Input/
Green LED blinks to indicate
that data transmission is
undergoing in 10/100 Base T
mode.
PS/2 Mouse
JP3
(on top)
1
3
PS/2 K/B (underside)
RJ 45
(on top)
USB0 (middle)
USB1 (underside)
Peripheral Power
RTL8139C
1
CD1
AUX1
1
AC'97
Audio
AUDIO1
14
2
1
33
Chapter 2 Hardware Setup
D.
I.
J.
K.
: Line Out/
Front Speaker Out
Rear Speaker Out
Center Subwoofer
Out
1
FAN1
RT2
+12V Power
1
i845PE
JP8
1
1
Intel
1
AGP 4X
FAN2
PCI 1
1
JAGP1
JAGP2
1
Intel
PCI 2
ICH4
PCI 3
USB2
USB3
10
10
1
1
JP4
LED1
1
1
1
JBAT1
1
JP11
IT8712F
LPC I/O
CN14
1
FAN3
1
