Quick Start Guide
IN710
Version: 1.2
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the
actual product and the written information in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN710 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZKTeco IN710

Summary of Contents for ZKTeco IN710

  • Page 1 Quick Start Guide IN710 Version: 1.2 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
  • Page 2 Overview 135.00mm Microphone Card Reading Area Indicator 5-inch HD Touchscreen Fingerprint Sensor Front Rear 23.50mm Reset Speaker Bottom Side...

  • Page 3: Finger Placement

    Description Interface Network Interface Type-C 12V Power In Access Control Finger Placement Recommended fingers: Index, middle, or ring fingers. Avoid using the thumb or pinky finger, as they are difficult to press accurately on the fingerprint reader.

  • Page 4: Installation Environment

    Installation Environment Please refer to the following recommendations for installation: Device Installation The IN710 requires no difficult installation, just fix the device on a flat table.

  • Page 5: Power Connection

    Power Connection AC Adapter DC V, 3A Recommended AC Adapter: Rating of 12V and 3A. To share the device's power with other devices, use a power supply with higher current ratings. Ethernet Connection After the device is powered on, connect the network connector via the Ethernet cable.
  • Page 6 Type-C Connection Connect the device and computer via a Type-C cable. Door Sensor, Exit Button and Lock Relay Connection Door Sensor and Exit Button:...
  • Page 7 Lock Relay Connection: The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-ON) is connected to 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-ON) is connected to 'NC' and 'COM' terminals. For an example, refer to the below-mentioned NC Lock:  1)Device not sharing power with the lock 2)Device sharing power with the lock...

  • Page 8: New User Registration

    New User Registration When there is no super administrator set in the device, click on to enter the menu. Add a new user and set User Role to Super Admin, then the system requests for the administrator’s verification before entering the menu. It is recommended to register a super administrator initially for security purposes.

  • Page 9: Access Control

    Ethernet Click on icon > [COMM.] > [Ethernet] to set the network parameters. If the TCP/IP communication of the device is successful, the icon will be displayed in the upper right corner of the standby interface. Access Control Click on icon >...
  • Page 10 System Click on icon > [System] to enter the system interface to set the related system parameters for optimizing the accessibility of the device. Attendance Record Click on icon > [ Attendance Search] > [Attendance Record to enter the personal record search, input the user ID and select the time range. Then the corresponding attendance record will be displayed.
  • Page 11 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
