Input 10-pin black connector (H3)
Module
Conn./Pin
Color
H3/1
Green
H3/2
Blue
H3/3
Red/White
H3/4
White/Violet
H3/5
Violet/Black
H3/6
White/Black
H3/7
Pink/White
H3/8
Violet
H3/9
Pink
H3/10
Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
9
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
[2]
(-) W2W Only - Trunk Input
(-)
[3]
(-)
(-)
(+) Keysense Input
(+)
(+)
(-) W2W Only - Ground When Running (Status) Input
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
No Connection
No Connection
No Connection
BIU right of steering column, white 34 pin plug (A), pin 4
No Connection
No Connection
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
(+/-)
Wire Color
Ref.
+
black/white
403.SUBARU2 1.25 2011 Subaru Outback
© 2016-11-16 Directed. All rights reserved.
