Key release connection

Only required for Pit Stop Mode or Manual Transmission vehicles.
BCM (behind the fuse box)
A B C D
(+) 12V
(-) Key Release 2: pin 3
7 6 5 4 3 2 1
19 18 17 16 15 14 13 12 11 10 9 8
27 26 25 24 23 22 21 21
35 34 33 32 31 30 29 29
(+) Key Release 1: pin 4
B281, 35-pin white conn. (B)
(right of steering column)
Connector location
7
(-) Ground
87
86 85
87a
30
87
86 85
(+) 12V
87a
30
(-) Key Release Output: Blue/Red: 12
© 2017-01-10 Directed. All rights reserved.
403.SUBARU2 1.25 2011 Subaru Outback
